IBM THINKPAD T22 - Page 129

2a
2
2a
2
2a
2a
Step Screw (quantity) Torque
For 13.3-in. LCD, LG (05K9636), 14.1-in. XGA LCD, Hitachi
(05K9568), 14.1-in. SXGA+ LCD, Hitachi (46L2493)
2 M2 × 4 mm, nylon-coated (4) 24.5 Ncm
(2.5 kgfcm)
For 14.1-in. LCD, LG (05K9567), SAMSUNG (05K9678), 14.1-in.
SXGA+ LCD, LG (05K9567), LG (46L2495)
2a M2 × 4 mm, nylon-coated (4) 24.5 Ncm
(2.5 kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T20, T21, T22 and T23 series 125
