2020 Inverter card
For access, remove these FRUs, in order:
v “1010 Battery pack” on page 61
v “1020 Ultrabay Plus device” on page 62
v “1050 Backup battery” on page 67
v “1070 Mini PCI adapter” on page 71
v “1080 Communication daughter card (CDC)” on page 74
v “1030 Hard-disk drive” on page 63
v “1090 Keyboard” on page 77
v “1120 Keyboard bezel” on page 87
v “1130 Hinge cover” on page 92
v “1140 LCD assembly” on page 94
v “2010 LCD front bezel” on page 114
Note
When you replace the inverter card, check the base
brightness of the LCD panel that is used with the
new inverter card, and use the correct inverter card
FRU for that base brightness. For more details
about the combination of the inverter card FRU and
the LCD panel FRU, see “LCD FRUs” on page 149.
3
1
2
(continued)
Removing and replacing a FRU
ThinkPad T30 115
