1050 Backup battery
DANGER
For access, remove this FRU:
v “1010 Battery pack” on page 61
1
3
2
Step Screw (quantity) Torque
1 M2.5 × 4.8 mm, nylon-coated (1) 0.392 Nm
(4 kgfcm)
When installing: Make sure that the battery connector is
firmly attached, and then secure the
screw.
The use only the battery in the parts listing for your
computer. Use of an incorrect battery can result in
ignition or explosion of the battery.
Removing and replacing a FRU
ThinkPad T30 67
