When installing: Install the keyboard, following the
directions below.
1. Attach the connector. (Step î6î in the removal
procedure.)
2. Make sure that the keyboard edges, shown in the
figure as (A) and (B), are under the frame.
(A)
(B)
3. Press the keys indicated by arrows to latch the
keyboard firmly in place.
(continued)
Removing and replacing a FRU
ThinkPad T30 79
