1170 Keyboard bezel for 14.1-in. LCD
models
For access, remove these FRUs in order:
v “1010 Battery pack for 14.1-in. LCD models” on page 71
v “1040 Hard disk drive” on page 75
v “1060 Keyboard” on page 79
v “1100 Palm rest or Palm rest with fingerprint sensor (for
14.1-in. LCD models)” on page 88
1
1
Step Screw (quantity) Color Torque
1 M2 × 19 mm, bind-head,
nylon-coated (2)
Black 0.245 Nm
(2.5
kgfcm)
(continued)
Removing and replacing a FRU
112 T40/T40p, T41/T41p, T42/T42p
