1190 PC Card slot assembly for 15.0-in.
LCD models
For access, remove these FRUs in order:
v “1020 Battery pack for 15.0-in. LCD models” on page 73
v “1040 Hard disk drive” on page 75
v “1060 Keyboard” on page 79
v “1110 Keyboard bezel or Keyboard bezel with fingerprint
sensor (for 15.0-in. LCD models)” on page 91
v “1160 Speaker assembly” on page 110
1
Step Screw (quantity) Color Torque
1 M2 × 5 mm, flat-head,
nylon-coated (2)
Black 0.204 Nm
(2.0
kgfcm)
(continued)
Removing and replacing a FRU
116 T40/T40p, T41/T41p, T42/T42p
