2060 Wireless antenna assemblies, LCD
panel, LCD cable assembly, hinges, and
LCD cover for 15.0-in. LCD models
For access, remove these FRUs in order:
v “1020 Battery pack for 15.0-in. LCD models” on page 73
v “1040 Hard disk drive” on page 75
v “1060 Keyboard” on page 79
v “1090 Bluetooth/Modem daughter card
(BMDC/BMDC-2)” on page 86
v “1110 Keyboard bezel or Keyboard bezel with fingerprint
sensor (for 15.0-in. LCD models)” on page 91
v “1120 Mini PCI adapter” on page 97
v “1210 LCD assembly for 15.0-in. LCD models” on page
123
v “2020 LCD front bezel for 15.0-in. LCD models” on page
155
v “2040 Inverter card for 15.0-in. LCD models” on page
159
1
1
1
1
1
1
Step Screw (quantity) Color Torque
1 M2 × 4 mm, bind-head,
nylon-coated (7)
Black 0.245 Nm
(2.5
kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T40/T40p, T41/T41p, T42/T42p Series 175
