1110 Keyboard bezel or Keyboard bezel
with fingerprint sensor (for 15.0-in. LCD
models)
For access, remove these FRUs in order:
v “1020 Battery pack for 15.0-in. LCD models” on page 73
v “1040 Hard disk drive” on page 75
v “1060 Keyboard” on page 79
Note
In models with the fingerprint sensor, the sensor has
been attached to the keyboard bezel FRU as the
child part. In case of the fingerprint sensor has any
defects and needs to be replaced, you need to
replace the keyboard bezel by following the
procedures in this section. The procedures are
same both for the keyboard bezel without the
fingerprint sensor and for the keyboard bezel with
the fingerprint sensor.
1
1
1
Step Icon Screw (quantity) Color Torque
1
1
M2 × 5 mm, flat-head,
nylon-coated (6)
Black 0.245 Nm
(2.5
kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T40/T40p, T41/T41p, T42/T42p Series 91
