5
4
3
3
3
Step Screw (quantity) Color Torque
3 M2 × 10 mm, flat-head,
nylon-coated (5)
Black 0.245 Nm
(2.5
kgfcm)
4 M2 × 4 mm, bind-head,
nylon-coated (2)
Black 0.245 Nm
(2.5
kgfcm)
In step 5, remove the Ultrabay Slim guide rail assembly
and the hard disk drive guide rail together.
(continued)
Removing and replacing a FRU
132 T40/T40p, T41/T41p, T42/T42p
