6
7
c
d
8
Step Screw (quantity) Color Torque
6 M2 × 3 mm, small-head,
nylon-coated (1)
Silver 0.245 Nm
(2.5
kgfcm)
7 M2 × 10 mm, flat-head,
nylon-coated (1)
Black 0.245 Nm
(2.5
kgfcm)
In step 8, remove the I/O plate bracket (c) and the
system board (d) together.
(continued)
Removing and replacing a FRU
142 T40/T40p, T41/T41p, T42/T42p
