FRU P/N CRU
ID
Base miscellaneous parts (15.0-in. LCD
models):
v Cover, PC Card slot
v Spring, PC Card slot cover
v Rubber foot (rear)
v Rubber foot (front)
v Battery lock knob L
v Battery lock latch L
v Battery lock knob R
v Link, battery lock
v Spring, battery lock
v Slide lever
v Slide lever spring
v Pull lever
v Pull lever spring
v Puller
v Rubber, shock absorber
v Insulation sheet
v Insulation, bottom
v Foam under fan
v Foam under system board, front
v Foam under system board, rear
v Cu plate, video
v Insulation, louver
v Screw caps (square, thin)
13R2914 N
System miscellaneous parts (14.1-in. LCD
models):
v Cable, RJ11-docking connector on system
board
v DC in cable
v (c) Hard disk drive guide rail
v Spacer for DSP connector
v (e) I/O plate bracket
v (f) Support structure
v Harness (left)
v (b) Antenna cable guide
v Bracket holder, LCD cable
v (d) EMI spring, CDC
v Connector bag
v Screw cap (square, thin)
Note:
Italicized letters in parentheses are
references to the exploded view on page 191.
91P8681 N
(continued)
Parts list
244 T40/T40p, T41/T41p, T42/T42p
