Automatic Image Setup
Image Setup ( )
The Setup Utility
included on the installation
CD is for displaying dot patterns.
They do not replace or modify the
display driver.
The Image Setup (
)
instructions require the monitor to
warm up for 15 minutes. This is
not required for normal operation.
By pressing the Auto key, you will
have direct access to Automatic
Image Setup Adjustment.
When you first use your monitor you must perform Image Setup ( ). This
procedure sets up your monitor to process the video signals from your
computer without image discoloration or smearing. After you perform Image
Setup ( ), the settings are stored and used each time you turn on the
monitor.
To optimize the displayed image a set-up utility is provided on the CD.
Operation of the utility is dependent on the operating system on your
computer. For correct operation locate the operating system on your
computer from the table below and follow the appropriate instructions. You
can choose to run
IMAGE SETUP ( ) for each operating system that you use.
This means that if you use your monitor while running any version of
Windows and also use it from within DOS (not a DOS window), you must run
IMAGE SETUP () for both Windows and DOS. You can run versions of IMAGE
S
ETUP () in any order.
Before you begin
IMAGE SETUP ( ) for your computer:
1. Make sure the computer’s video mode is set in the range of the
supported screen resolution shown in the table on page 20.
The
IMAGE SETUP ()
process only applies to the
current screen mode. When a new
mode is selected, repeat this
section to reset the monitor.
You should perform IMAGE SETUP ( ) for each screen mode you use.
Operating System Corresponding Image Setup Procedure
DOS
Image Setup ( ) for DOS on page 12
Windows 95, Windows 98,
Windows 2000,
Microsoft Windows NT
®
,
Windows Me or Windows XP
Image Setup ( ) for Windows 95, Windows 98,
Windows NT, Windows 2000, Windows ME,
Windows XP on page 13
To Next Page
