L170_E.fm Page 18 Friday, February 21, 2003 4:32 AM
18
Image Setup Automatic
Activates automatic image adjustment.
Manual
•Clock
• Phase
Use the
or button to adjust away the interference.
If satisfactory results are not obtained using the Phase
adjustment, use the Clock adjustment and then use Phase
again.
Properties
Color
Adjusts intensity of red, green and blue.
1. Mode 1
(Preset Mode)
• 6500K
• 7200K
• 9300K
6500K adjusts the screen more red.
7200K adjusts the screen to the default color settings.
9300K adjusts the screen more blue.
2. Mode 2
(Custom)
•Red
• Green
•Blue
Increases or decreases 'red'.
Increases or decreases 'green'.
Increases or decreases 'blue'.
Sharpness
1. Mode 1
adjusts the image softer.
2. Default
returns the image sharpness to the default settings.
3. Mode 2
adjust the image sharper.
OSD Icon on
Main Menu
Submenu Description
Controls and Adjustments
To Next Page
