Verify host adapter settings
Note: The example below uses the Adaptec 2940UW controller with DPSS-318350.
1. Insert a bootable diskette into the diskette drive.
2. Turn the computer on. You should see the drive model displayed when the system is booting.
3. Verify the adapter settings.
4. Press [CTRL] [A] to enter the Adaptec SCSI setup utility. The following screen is displayed.
Adaptec AHA-2940 Ultra/Ultra W BIOS v1.23
(c) 1996 Adaptec, Inc. All Rights Reserved.
Press <Ctrl><A> for SCSISelect (TM) Utility!
SCSI ID:LUN NUMBER # : # 0:0 - IBM OEM DPSS-318350 - Drive C: (80h)
CPU/CLK : Pentium/133MHz Base Memory : 640 KB
Math Coprocessor : Installed Extended Memory : 15360 KB
Fixed Disk 0 : None Shadow RAM : 384 KB
Fixed Disk 1 : None Internal Cache : 16 KB, Enabled
5. Press [CTRL] [A] to enter the Adaptec SCSI select utility. The following screen is displayed.
Adaptec AHA-2940 Ultra/Ultra W SCSISelect (TM) Utility v1.23
Configure/View Host Adapter Settings
SCSI Disk Utilities
AHA-2940 Ultra/Ultra W at Bus:Device 00:0Fh
Would you like to configure the host adapter, or run the SCSI disk utilities:
Select the option and press <Enter>. Press <F5> to switch between color and
monochrome modes.
Options
IBM storage products
Page 13
IBM Technology Group Support Center 07N5612IG10
