Icar RPC 8BGA - Page 25

s. 25 / 40
P21.n.06
Unit of measurement
Usr
Umn
(Text – 6 characters)
P21.n.07
Reset source
Usr
OFF
OFF-ON-INPx-OUTx-LIMx-REMx
P21.n.08
Channel number (x)
Usr
1
1-8
For more information download the complete manual of the RPC 8BGA power factor controller from the web site www.icar.com download area concerning the low voltage power
factor correction systems.
M22 – ANALOG INPUTS (AINn,n=1..4)
Psw
(M15)
UoM
Default
Range
P22.n.01
Input type
Usr
OFF
OFF
0..20mA
4….20mA
0…10V
-5V…+5V
PT100
P22.n.02
Start of scale value
Usr
0
-9999 - +9999
P22.n.03
Multiplier
Usr
x1
/100 – x1k
P22.n.04
End of scale value
Usr
100
-9999 - +9999
P22.n.05
Multiplier
Usr
x1
/100 – x1k
P22.n.06
Description
Usr
AINn
(Testo – 16 caratteri)
P22.n.07
Unit of measurement
Usr
UMn
(Testo – 6 caratteri)
For more information download the complete manual of the RPC 8BGA power factor controller from the web site www.icar.com download area concerning the low voltage power
factor correction systems.
M23 – ANALOG OUTPUTS (AOUn,n=1..4)
Psw
(M15)
UoM
Default
Range
P23.n.01
Output type
Usr
OFF
OFF
0..20mA
4….20mA
0…10V
-5V…+5V
P23.n.02
Reference measurement
Usr
OFF
OFF- (misure)
P23.n.03
Channel number (x)
Usr
1
OFF / 1-99
P23.n.04
Start of scale value
Usr
0
-9999 - +9999
P23.n.05
Multiplier
Usr
x1
/100 – x10k
P23.n.06
End of scale value
Usr
0
-9999 - +9999
P23.n.07
Multiplier
Usr
x1
/100 – x10k
Note: this menu is divided into 4 sections for the analog outputs AOU1...AOU4
available with OUT 2AN expansion modules
P23.n.01 - Specifies the type of output analog signal. The sensor should be connected to the appropriate terminal on the basis of the type selected. See analog output module manual.
P23.n.02 - Measurement on which the analog output value depends.
P23.n.03 – If the reference measurement is an internal multichannel measurement (AINx for example), the channel is defined.
P23.n.04 and P23.n.05 - Define the value of the measurement that corresponds to a min. output value in the range (0mA, 4mA, 0V, -5V, etc.).
P23.n.06 and P23.n.07 - Define the value of the measurement that corresponds to a max. value in the range (20ma, 10V, +5V, etc.).
Application example: The analog output AOU2 must emit a 0..20mA signal proportional to tha total active power, form 0 to 500kW.
So, we must program section 2 of this menu, that is referred to AOU2.
P23.2.01 = 0…20mA
P23.2.02 = kW tot
P23.2.03 = 1 (not used)
P23.2.04 = 0
P23.2.05 = x1
P23.2.06 = 500
P23.2.07 = x1k
M24 – PULSES
(PULn, n=1…6)
Psw
(M15)
UoM
Default
Range
P24.n.01
Pulse source
Usr
OFF
OFF-Kwh-kvar-kVA
P24.n.02
Counting unit
Usr
100
10/100/1k/10k
P24.n.03
Pulse duration
Usr
s
0.1
0.1-1.00
For more information download the complete manual of the RPC 8BGA power factor controller from the web site www.icar.com download area concerning the low voltage power
factor correction systems.
M25 – USER ALARMS
(UAn, n=1…8)
Psw
(M15)
UoM
Default
Range
P25.n.01
Alarm source
Usr
OFF
OFF-INPx-OUTx-LIMx-REMx
P25.n.02
Channel number (x)
Usr
1
1-8
P25.n.03
Text
Usr
UAn
(testo – 20 char)
For more information download the complete manual of the RPC 8BGA power factor controller from the web site www.icar.com download area concerning the low voltage power
factor correction systems.
M26 – ALARM PROPERTIES
(ALAn, n=1…xxxx)
Psw
(M15)
Default
Range
P26.n.01
Alarm enable
Adv
(see table)
OFF – ON
P26.n.02
Retnitive
Adv
(see table)
OFF - RIT
P26.n.03
Operating mode
Adv
(see table)
AUT-MAN
AUT
P26.n.04
Global alarm 1
Adv
(see table)
OFF – GLB1
P26.n.05
Global alarm 2
Adv
(see table)
OFF – GLB2
P26.n.06
Global alarm 3
Adv
(see table)
OFF – GLB3
P26.n.07
Step disconnection
Adv
(see table)
OFF
IMMEDIATE
SLOW
P26.n.08
Slave disconnection mode
Adv
(see table)
GENERAL - LOCAL
P26.n.09
Inhibition from input
Adv
(see table)
OFF - ON
P26.n.10
Modem call
Adv
(see table)
OFF - MDM
P26.n.11
Not shown on LCD
Adv
(see table)
OFF - NOLCD
P26.n.12
Alarm delay
Adv
(see table)
OFF/ 1-120
P26.n.13
Delay UoM
Adv
(see table)
MIN-SEC
