Harmonic protection
Module nr. n
Temperature 2 too high
The temperature 2 measured by the MCP5 module is higher than threshold set with
P18.n.13.
The slave nr. X does not communicate with the master. Check the RS-485 wiring.
Clean the air intake filter of the ventilation system.
Check the currents for each step, the efficiency of the fuses and contactors.
Perform the operations in A20 and A21 and check the capacitors conditions or contact
technical support.
User-defined alarm, as specified by parameters of menu M25.
22.2. Alarm properties
Various properties can be assigned to each alarm, including user alarms (User Alarms, UAx):
Alarm enabled - General enabling of the alarm. If the alarm isn't enabled, it's as if it doesn't exist.
Retained alarm - Remains in the memory even if the cause of the alarm has been eliminated.
Operating mode – Operating modes where the alarm is enabled.
Global alarm 1 -2 -3 - Activates the output assigned to this function.
Step disconnection mode – Defines whether and how the capacitor steps must be disconnected when
the alarm is present. OFF = no disconnection, SLOW = gradual disconnection, FAST = Immediate
disconnection.
Slave disconnection mode – Defines, for Master-Slave applications, if when this alarm arises, the
disconnection is extended to all the step of the system (GENERAL) or only to the output of the
interested panel (LOCAL).
Inhibition - The alarm can be temporarily disabled by activating an input that can be programmed with
the Inhibit function.
Modem call – The alarm will be signalled remotely by sending a modem call under the conditions and
modality defined in modem parameters.
No LCD - The alarm is managed normally, but not shown on the display.
Delay time – Time delay in minutes or seconds before the alarm is generated.
22.3. Alarm properties table
