24. Input function table
The following table shows all the functions that can be attributed to the INPn programmable digital
inputs.
For more information download the complete manual of the RPC 8BGA power factor controller from
the web site www.icar.com download area concerning the low voltage power factor correction systems.
Free user configurable input INPx. Used for instance to generate a user alarm UA or to count on a CNT
counter.
When active, switches system to AUT mode
When active, switches system to MAN mode
When active, selects the cosphi setpoint x (x=1…3).
Locks access to setup menu and command menu.
Selectively disables alarms that have inhibit property set to ON.
25. Output function table
The following table shows all the functions that can be attributed to the OUTn programmable digital
inputs.
For more information download the complete manual of the RPC 8BGA power factor controller from the web site
www.icar.com download area concerning the low voltage power factor correction systems.
Output always de-energized
Energised when global alarm 1 is active
Energised when global alarm 2 is active
Energised when global alarm 3 is active
Active when the regulator is in MAN mode
Active when the regulator is in AUT mode
Output driven by LIM limits
Output driven by PUL pulses
Output is remote controller by REM variable
When the selected Axx alarmi s present, the output ias activated (x=1… alarm number)
When the selected UAx user alarm is present, the output is activated (x=1… 8)
26. Measure table for Limits / analog outputs
