CR IMMO User Manual
2
17 INS Cable V1
Connect the programmer and vehicle dashboard,
and then place the probe (the yellow lead) to the
designated area.
1
18 INS Cable V2
After removing the vehicle dashboard, connect
programmer, vehicle dashboard, and the cable.
1
19 MCU Cable V1 To connect the programmer and MCU. 1
20 Bench Mode Cable
Connect the programmer and the engine to read
engine or gearbox ECU (Connect engine ECU with
the BENCH mode cable based on BENCH mode
diagram).
1
21 Matching Adapter A
To connect the BENCH mode cable and gearbox
ECU/engine.
5
22 Matching Adapter B
To connect the BENCH mode cable and gearbox
ECU/engine.
6
23 Matching Adapter C
To connect the BENCH mode cable and gearbox
ECU/engine.
7
24 Matching Adapter D
To connect the BENCH mode cable and gearbox
ECU/engine.
8
25 Matching Adapter E
To connect the BENCH mode cable and gearbox
ECU/engine.
6
26
Switching Power
Supply
Supply power to the programmer. 1
27 Password envelope
A piece of paper bearing Product S/N and
Activation Code, which is required for your
registration.
1
28 User Manual 1
2 Overview
2.1 Introduction
CR IMMO, developed by
Icarsoft Technology Inc.
is specially designed as a
comprehensive immobilizer programmer. It can work with the VCI (Vehicle
Communication Interface) dongle to perform full car models and full systems
diagnosis (including reading/clearing the diagnostic trouble codes and reading
data stream etc.). Additionally, it also can work with the IM2000 PRO to
perform anti-theft matching and anti-theft programming operations.
