Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
16
Product Nomenclature
Model Selection 8 CHPW 09 P X F 1 S X X U U G X E X X X W X A
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Primary Part
Item
#
Matrix
Name
Code
String
Value
Description
1 POWER
8 208V/1PH/60HZ
7 277V/1PH/60HZ
5 115V/1PH/60HZ
2 UNIT TYPE CHPW Console WSHP
3
CAPACITY
(BTUH)
09 9,000 (~3/4-Ton)
13 13,000 (~1-Ton)
16 16,000 (~1-1/4-Tons)
19 19,000 (~1-1/2-Tons)
4 MOTOR
P PSC Motor
E EC Motor
5 DISCONNECT
F Fused Disconnect
N Non-Fused Disconnect
P Line Cord With Plug (18")
X Terminal Block with Cover
6 UNIT CONFIG.
F Flat Top
E Flat Top with Removable Chassis
S Sloped Top
R Sloped Top with Removable Chassis
T Flat Top with Front Intake
U Flat Top with Removable Chassis and Front Intake
V Sloped Top with Front Intake
W Sloped Top with Removable Chassis and Front Intake
C Custom Enclosure
7
ENCLOSURE
COLOR
1 Antique White
2 Arctic White
3 Custom
8 INSULATION
S Standard Insulation (12.7 mm (1/2") Fiberglass)
F 1/2” Foil Faced Insulation
9 P-TRAP
I Internal P-Trap
X No P-Trap
10 RISERS X Riser Options Not Applicable
11
PIPE
ORIENTATION
L Left Hand
R Right Hand
U Universal (allows for field connection on either side)
12 WIRE WHIPS
A Wall mounted with 6.5-foot wire whip
B Wall mounted with 10-foot wire whip
C Wall mounted with 12-foot wire whip
D Wall mounted with 30-foot wire whip
E Wall mounted with 50-foot wire whip
F Standard 18" wire whip
U Unit mtd controls
13 DRAIN PAN
G Powder Coated Galvanized Drain Pan
S Stainless Steel Drain Pan
X No Drain Pan
Item
#
Matrix
Name
Code
String
Value
Description
14
COMPRESSOR
BLANKET
B Sound Attenuation Blankets
X No Compressor Blanket
15 CONTROLS
C Non-Programmable LCD Touchpad Thermostat (ELA-12690)
D
Non-Programmable LCD Thermostat (ELA-8842 via dip
switch)
E 7-Day Programmable LCD Thermostat (ELA-8842)
F 7-Day Programmable Touchscreen Thermostat (ELA-13086)
G Nest Thermostat (ELA-10665)
H
Habitat Wireless Wi-Fi Thermostat with Water Leak Detector
(ELA-13161)
I Non-Programmable LED Touchpad Thermostat (ELA-10328)
X Field Mounted By Others
16
MOTORIZED
VALVES
A 2-Way Motorized Valve NO
B 2-Way Motorized Valve NC
C Custom Valve Option
D 3-Way Motorized Valve NO
E 3-Way Motorized Valve NC
X No Valve Option
17 FLOW VALVES
A Autoflow Valve (HAYS 2510/2517)
B Autoflow Valve/Shutoff combo (HAYS 2519)
H Autoflow Valve (HAYS 2515) [high GPM only]
C Autoflow Valve w/PT Ports (YR Flow Valve)
M Manual Balancing Valve
Y Y-Strainer
F Autoflow Valve w/PT Ports (YR Flow Valve) + Strainer
D Autoflow Valve + Strainer
E Autoflow Valve/Shutoff combo + Strainer
G Manual Balancing Valve + Strainer
X No Flow Valves
18
CONDENSATE
PUMP
I Internal Condensate Pump
E External Condensate Pump
X No Condensate Pump
19 FILTERS
A MERV 8 Filter
B MERV 12 Filter
C MERV 13 Filter
W Washable Filter
P Fiberglass Filter
X No Filter
20 AIR VENTS
M Manual Air Vent
T Bleed Tee
X No Air Vent
21
VALVE
SHIPPING
OPTIONS
A Assembled
S Shipped Loose
X No Valves
To Next Page
