ICE AIR 5CHPW13 - Technical Specifications

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
4
Physical Data
Model 5CHPW09 5CHPW13 8CHPW09 8CHPW13 8CHPW16 8CHPW19 7CHPW09 7CHPW13 7CHPW16 7CHPW19
Compressor Type (1 EA) Rotary
Refrigerant R410A
Refrigerant Factory Charge (oz) 26.5 28.2 26.5 28.2 30 32.5 26.5 28.2 30 32.5
Fan Motor (HP) 1/20 1/12 1/12 1/12 1/8 1/6 1/12 1/12 1/8 1/6
Blower Wheel Size
(Diameter x Width) (IN)
1 @ 5.25” x 6.25” 2 @ 5.25” x 6.25” 1 @ 5.25” x 6.25” 2 @ 5.25” x 6.25”
Air Coil Dimension (IN) 19.5x10.0 19.5x10.0 19.5x10.0 19.5x10.0 27.5x10.0 27.5x10.0 19.5x10.0 19.5x10.0 27.5x10.0 27.5x10.0
Standard Filter - 1" (IN) 22.75x10.0 22.75x10.0 22.75x10.0 22.75x10.0 30.75x10.0 30.75x10.0 22.75x10.0 22.75x10.0 30.75x10.0 30.75x10.0
Weight (lb) 175 180 180 180 190 210 180 180 190 210
Model 5CHPW09 5CHPW13 8CHPW09 8CHPW13 8CHPW16 8CHPW19 7CHPW09 7CHPW13 7CHPW16 7CHPW19
Flow Rate (GPM) 2.25 3.25 2.25 3.25 4 4.75 2.25 3.25 4 4.75
Water Connection (IN) 1/2” NPT
Condensate Hose
Connection Size (IN)
5/8”
Mode Cooling °F Heating °F
Ambient Air min-max DB 50-100 50-85
Return Air Min DB/WB 65/60 50
Return Air Max DB/WB 95/75 80
Entering Water Min*-Max 60-110 60-90
Regardless of the system being utilized, optimum performance can only be achieved through adjustment to the recommended water flow at
each individual unit. Refer to unit requirements in the following table below:
* Additional insulation may be required
Typical Water Side Data
Unit Operating Limits
