Ice i20NBV User Manual

21 i20NBV
OPERATOR MANUAL
CONTROL CONSOLE GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
1 8014063 BATTERY CAPACITY INDICATOR 1
2 8134741 CONTROL PANEL DECAL, I20NBV 1
3 1221512 SCREW M5×12 17
4 1422513 LOCK WASHER M5 6
5 1421510 FLAT WASHER M5×DIA10×1.0 13
6 8134811 CONTROL PANEL, I20NBV 1
7 8134015 GASKET 1
8 8014006 WATERPROOF SWITCH 2
9 1221306 SCREW M3×6 2
10 8134005A CONTROL HOUSING, I20NBV 1
11 1021616 HEX BOLT M6×16 5
12 1421618 PLAIN WASHER M6×DIA18×1.6, SS 10
13 8114707 RELAY 1
14 8114703 OVERLOAD PROTECTOR, 35A 1
15 8134006 PLATE, CIRCUIT BREAKERS MOUNTING 1
16 8144025 LABEL, CIRCUIT BREAKER 1
17 1221515 PH SCREW M5×15 4
18 1123507 LOCK NUT M5 2
19 1123305 LOCK NUT M3 4
20 8113010 BRACKET, CONNECTOR MOUNTING 1
21 8113020 CONNECTOR 1
22 1434300 LOCK WASHER, TOOTH, M3 4
23 1211325 SCREW M3×25 2
24 8134060 PLATE, ON BOARD BATTERY CHARGER 1
25 8134061 CLEAR COVER 1
26 1221416 SCREW M4×16 2
27 8210421 RELAY 1
28 1421409 FLAT WASHER M4×DIA9×0.8 2
29 1421510 FLAT WASHER M5×DIA10×1 1
30 1123406 LOCK NUT M4 4
31 8114005 CONNECTOR 1
32 1021840 HEX BOLT M8×40 2
33 1422821 LOCK WASHER M8 12
34 1421828 FLAT WASHER M8×DIA28×3 2
35 1021630 HEX HEAD BOLT M6×30, SS 1

Ice i20NBV Specifications

General

Brand	Ice
Model	i20NBV
Category	Scrubber
Language	English
