i20NBV 22
OPERATOR MANUAL
CONTROL CONSOLE GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
36 8134082 CABLE, SQUEEGEE LIFT 1
37 8014101 LIFTING ROPE SPACER 1
38 1021610 HEX HEAD BOLT M6×10, SS 1
39 1421616 FLAT WASHER M6×DIA16×1.0 1
40 1123608 LOCK NUT M6 3
41 8014012 BAFFLE 1
42 8113111 NYLON FLAT WASHER DIA12.9×DIA25.4×0.8 1
43 1121605 HEX NUT M6 2
44 8134501 BRACKET 1
45 8134081 SLEEVEE 1
46 1421132 FLAT WASHER M12×DIA32×1.5 1
47 8134080 SQUEEGEE LIFTING HANDLE 1
48 8113104 BALL KNOB M8 1
49 1222641 SUNK HEAD SCREW M6×40 2
50 8210112 HOOK, POWER CORD 2
51 8014054 STRAIN RELIEF 1
52 6210111 CLAMP, DRAIN HOSE 1
53 8134070 REAR PLATE, CONTROL CONSOLE 1
54 1421824 FLAT WASHER M8×DIA24×2 10
55 1021820 HEX BOLT M8×20 10
56 8114712 MICRO SWITCH 1
57 1021320 SCREW M3×20 2
58 8134022 BRACKET, SWITCH 1
59 8114402 BRACKET, SPRING 1
60 1521616 SCREW M6×16, HEX SCOKET 2
61 1534608 SET SCREW M6×8 4
62 8134301 LEVER, BAIL 1
63 8114300 ACTUATOR 1
64 8114306 SPRING 1
65 1535630 SET SCREW M6×30 1
66 8114101 SHAFT 1
67 1021512 HEX HEAD BOLT M5×12, SS 2
68 8132071-US CHARGER BRACKET,KIT 1
69 8112030A BATTERY CHARGER POWER CORD, KIT 1
70 8132020-PC ON BOARD BATTERY CHARGER 1
To Next Page
