IceTech Evolution Line Xtreme 40 User Manual

15
BLASTING HOSE
1. Hose coupling – for connection on front
of the dry ice blasting machine.
2. Signal cable – for connection on front of
the dry ice blasting machine.
3. Signal cable – for connection to the
blasting gun.
4. Hose coupling – for connection to the
blasting gun.
IceTech offers three different types of blasting hoses:
HD hoses, ber reinforced silicon hoses and Teon hoses.
ICEGUN EVOLUTION LINE W/ LIGHT
1. Light.
2. Safety switch.
3. Two-step trigger: (Blasting with dry ice
AND air, - Blasting with AIR ONLY).
4. Signal cable.
5. Standard Round Nozzle -
interchangeable.
6. Nozzle adapter.
Dim. (mm/inch) without nozzle:
Length: 270 / 10.63
Width: 60 / 2.36
Height: 225 / 8.86
Weight without nozzle:
g: 1100 / lb: 2.42
