IceTech Evolution Line Xtreme 40 User Manual

30
LONG LIFE SPLITTERNETS
CORRECT USE
Splitternet mm
1.5 2 2.5 3
Max Ice
kg/h
Min. Air
Max Ice
kg/h
Min. Air
Max Ice
kg/h
Min. Air
Max Ice
kg/h
Min. Air
Ø5 20 4 25 4 30 4 35 4
Ø6 25 4 30 4 35 3.5 40 3.5
Ø7 30 3 35 3 40 3 45 3
Ø8 35 3 40 3 45 3 50 3
Ø9 50 3 70 3 100 2 120 2
Ø10 60 2 80 2 120 2 150 2
• Pulverizes dry ice pellets
• Light-weight aluminum
• To be used when very low abrasion is required,
cleaning sensitive objects like electrical
switchboards, printed circuits, etc.
High and Low IceSplitters
