Tag-numbers for PR350H V3
P296-1-14201-B
18/08/2015
1 of 2
ASPECT ASPECT DESCRIPTION TAG TAG DESCRIPTION
Beskrivelse Digital In Digital Out Analog In Analog Out Datablad relative links
DI=V01 Filter unit -V1 Filter for filter unit
DI=V01 Filter unit -Q1 Man. valve before filter unit
DI=V01 Filter unit -Q2 Valve for degassing filter unit 101099 032F101 00 EVR 15
DI=V01 Filter unit -Q2-K1 Solenoid for valve, filter unit 103005 018F6801 1 datasheet\ICPD600A202.indd.pdf
DI=V01 Filter unit -QF1 Safety valve for filter unit 101222 25 bar
DI=V01 Filter unit -QL1 Float valve for filter unit
DI=W01 Pipe system -Q1 Valve 1 for inlet 502415 3/4" Ball valve
DI=W01 Pipe system -Q1-MA1 Actuator for valve 1, inlet 502415 Single acting pneu. Actuator
DI=W01 Pipe system -Q3 Check valve 3 for degassing Kontraventil RF
DI=W01 Pipe system -QF1 Safety valve 1 for pipe system 101221 27,6 bar
DI=W01 Pipe system -QF2 Safety valve 2 for pipe system 101221 27,6 bar
DI=W01 Pipe system -QF3 Safety valve 3 for pipe system 101223 1 bar
DI=W01 Pipe system -TT1 Temperatur transmitter T1 for liquid 103024 TSPT100A PT100 datasheet\Sensonic_LTT-TS-TSPT.pdf
DI=W01 Pipe system -TT2 Temperatur transmitter T2 for liquid 103024 TSPT100A PT100 datasheet\Sensonic_LTT-TS-TSPT.pdf
DI=W01 Pipe system -TT3 Temperatur transmitter T3 for degassing Modstandsføler Type 372 PT100 datasheet\9M011781.pdf
DI=W01 Pipe system -TP1 Pressure transmitter P1 for liquid 500408 Endress+Hauser 0-40bar 4-20mA ud PMP131-A4401A1X 4-20mA datasheet\PMP131.pdf
DI=W01 Pipe system -TP3 Pressure transmitter P3 for gas 500260 Endress+Hauser 0-4bar 4-20mA ud PMP131-A4401A1Q 4-20mA datasheet\PMP131.pdf
DI=W01 Pipe system -E1 Heat exchanger SWEP B60x60,2x42U+2x66,85
DI=W01 Pipe system -V1 Filter for CO2 liquid
DI=G01 Extruder 1 for dry ice pellets
DI=G01 Extruder 1 for dry ice pellets -Q1 Valve 1 for pellet extruder 1 30° V-ball valve single acting pneu. actuator
DI=G01 Extruder 1 for dry ice pellets -Q1-MA1 Actuator for valve 1 Solenoid 24V DC
DI=G01 Extruder 1 for dry ice pellets -Q1-BG1 Position switch for valve 4 open Induktiv endestop 1 datasheet\5300.pdf
DI=G01 Extruder 1 for dry ice pellets -Q1-BG2 Position switch for valve 4 closed Induktiv endestop 1 datasheet\5300.pdf
DI=G01 Extruder 1 for dry ice pellets -Q2 Check valve 2 for pellet extruder 1 Kontraventil RF
DI=G01 Extruder 1 for dry ice pellets -TP1 Pressure transmitter 1 for pellet extruder 1 500260 Endress+Hauser 0-4bar 4-20mA ud PMP131-A4401A1Q 4-20mA datasheet\PMP131.pdf
DI=G01 Extruder 1 for dry ice pellets -PP1 Manometer for pellet extruder 1 500247 0-10 Bar
DI=G01 Extruder 1 for dry ice pellets -G1 Extruder for dry ice pellets
DI=G01 Extruder 1 for dry ice pellets -G1-MO1 Hydraulic cylinder for pellet extruder 1
DI=G01 Extruder 1 for dry ice pellets -G1-TG1 Position transmitter 1 for pellet extruder 1 Balluf BTL7-V50E-M0400-B-C003 Til EtherCAT EtherCAT datasheet\BA BTL7-V50E-M -ABYZ(8)-C003_910168_F14_EN.pdf
DI=G01 Extruder 1 for dry ice pellets -G1-Q3 Valve 3 for pellet extruder 1
DI=G01 Extruder 1 for dry ice pellets -Q3-MO2 Hyd. cylinder for pellet extruder 1 valve 3
DI=G01 Extruder 1 for dry ice pellets -Q3-TG2 Position transmitter 1 for pellet extruder 1 Balluf BTL7-V50E-M0300-B-C003 Til EtherCAT EtherCAT datasheet\BA BTL7-V50E-M -ABYZ(8)-C003_910168_F14_EN.pdf
DI=G01 Extruder 1 for dry ice pellets -Q5 Valve 1 for pellet extruder 1 101099 032F101 00 EVR 15
DI=G01 Extruder 1 for dry ice pellets -Q5-K2 Solenoid 1 for pellet extruder 1 valve 1 103005 018F6801 1 datasheet\ICPD600A202.indd.pdf
DI=HU01 Hydraulic unit for pellet extruder
DI=HU01 Hydraulic unit for pellet extruder -C1 Tank for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -C1-V1 Refill filter for hydraulic tank
DI=HU01 Hydraulic unit for pellet extruder -C1-BL1 Level switch for hydraulic tank Niveauvagt LM1 – CTPA 175 NA 1 datasheet\12-186488_gb.pdf
DI=HU01 Hydraulic unit for pellet extruder -C1-PL1 Sight glass level for hydraulic tank
DI=HU01 Hydraulic unit for pellet extruder -G1 Pump for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -G1-M1 Motor for hydraulic pump Elmotor 11 kW 3x400/690 50Hz inkl. 3 x PTC thermistor 1
DI=HU01 Hydraulic unit for pellet extruder -V2-PP1 Manometer for filter
DI=HU01 Hydraulic unit for pellet extruder -Q1 Valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -Q1-KO1 Solenoid for hydraulic valve 1 Spole 24VDC med effekt 27W ADC cetop 3 ADC3E16EM 001 1 datasheet\ADC cetop 3.pdf
DI=HU01 Hydraulic unit for pellet extruder -Q2 Valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -Q2-KO1 Solenoid for hydraulic valve 2 Spole 24VDC med effekt 27W ADC cetop 3 ADC3E16EM 001 1 datasheet\ADC cetop 3.pdf
DI=HU01 Hydraulic unit for pellet extruder -Q3 Valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -Q3-KO1 Solenoid for hydraulic valve 3 Spole 24VDC med effekt 27W ADC cetop 3 ADC3E16EM 001 1 datasheet\ADC cetop 3.pdf
DI=HU01 Hydraulic unit for pellet extruder -Q4 Valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -Q4-KO1 Solenoid for hydraulic valve 4 Spole 24VDC med effekt 27W ADC cetop 3 ADC3E16EM 001 1 datasheet\ADC cetop 3.pdf
DI=HU01 Hydraulic unit for pellet extruder -Q7 Restrictor valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -Q8 Check valve for hydraulic cylinder
DI=HU01 Hydraulic unit for pellet extruder -Q9 Valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -Q9-KO1 Solenoid for hydraulic valve 9 Spole 24VDC med effekt 27W ADC cetop 3 ADC3E01CM 001 1 datasheet\ADC cetop 3.pdf
DI=HU01 Hydraulic unit for pellet extruder -Q9-KO2 Solenoid for hydraulic valve 9 Spole 24VDC med effekt 27W ADC cetop 3 ADC3E01CM 001 1 datasheet\ADC cetop 3.pdf
DI=HU01 Hydraulic unit for pellet extruder -Q11 Valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -Q11-KO1 Solenoid for hydraulic valve 11 Spole 24VDC med effekt 27W ADC cetop 3 ADC3E01EM 001 1 datasheet\ADC cetop 3.pdf
DI=HU01 Hydraulic unit for pellet extruder -Q15 Valve for hydraulic drain
DI=HU01 Hydraulic unit for pellet extruder -Q15-KO1 Solenoid for hydraulic valve 15 Spole 24VDC med effekt 27W ADC cetop 3 ADC3E01CM 001 1 datasheet\ADC cetop 3.pdf
DI=HU01 Hydraulic unit for pellet extruder -QP1 Pressure valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -QP2 Pressure valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -QP3 Pressure valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -QP4 Pressure valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -QP9 Pressure valve for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -C1-TT1 Temperature transmitter for hydraulic unit Temperatur føler 0-100°C AVN no.: 666690=666680 PT100 datasheet\12-666680_dk.pdf
DI=HU01 Hydraulic unit for pellet extruder -TP1 Pressure transmitter for hydraulic unit Tryktransmitter er 0-200 bar 4-20mA MBS 33 060 G 1756 4-20mA datasheet\12-634129_gb.pdf
DI=HU01 Hydraulic unit for pellet extruder -C1-V2 Filter for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -X1 Distribution block 1 for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -X3 Distribution block 3 for hydraulic unit
DI=HU01 Hydraulic unit for pellet extruder -PP2 Manometer for hydraulic unit
DI=G1-Q3 Extruder plate 1 heating
DI=G1-Q3 Extruder plate 1 heating -TT1 Temperature transmitter 1 501979 Temperatur transmitter 2 ledet PT100 PT100
