Industrivej 62
DK-6740 Bramming
Denmark
Version: 2.0
IceTech PR350H
User’s manual
Date: 2017.07.03
Init: JM
In such cases, the liability of the manufacturer will be solely confined to any manufacturing faults/errors made prior to
the machine being delivered and before repairs/replacements have been made.
INSTRUCTION – UNPACKING AND PREPARATIONS BEFORE INSTALLATION
Your new IceMaker has been assembled as one unit. In order to avoid damages during transport the IceMaker has been
bolted onto the transport pallet.
Unpacking and Examination for Transport Damages
1. Examine the transport box for any damages occurred during transportation.
2. Remove the straps that secure the transport box to the pallet.
3. Remove the top and side plates from the transport box.
4. Remove the straps that secure the IceMaker to the pallet.
5. Unbolt the 4 bolts that secure the IceMaker to the pallet.
6. Examine the IceMaker for external transport damages.
7. Open the cabinet door at the control panel and examine the IceMaker for internal transport damages.
Requirements on the Environment Surrounding the IceMaker
•
The IceMaker must be sheltered from wind and weather.
•
The ambient temperature must be min. +5°C (+41°F).
How to Lift / Transport the IceMaker
IceMaker PR350H: Drawing no. A1
•
The IceMaker is supplied with thread holes for lifting eyes. Always use lifting eyes to lift the IceMaker.
•
Always lift the IceMaker according to the lifting Instruction in this manual.
•
Lifting over persons and animals is prohibited.
•
Always use a forklift truck to transport the IceMaker.
•
Pick up the IceMaker from the side as shown in the drawings.
•
Transport the IceMaker upright.
•
Make sure that the forks are sufficiently long to fully engage the IceMaker.
•
Always check that the forks are adjusted to maximum width.
PR350H:
Min. load capacity of forklift truck: 1150 kg /2535 lbs
Min. fork length: 1.0 m
Floor Characteristics and Minimum Clear Distances
IceMaker PR350H: Drawing no. A2
•
The IceMaker must be placed on a horizontal concrete floor with an adequate load-carrying capacity, free from
crack formation and suitable for bolting the IceMaker to it.
•
The minimum clear distances must be observed to provide sufficient space for opening the cabinet doors and
servicing the IceMaker.
Installation of the IceMaker
The installation of the IceMaker must be carried out by one of Cold Jet’s service technician, or by a technician approved
by Cold Jet.
