Industrivej 62
DK-6740 Bramming
Denmark
Version: 2.0
IceTech PR350H
User’s manual
Date: 2017.07.03
Init: JM
TECHNICAL DATA
Rated Output:
kg/h: up to 350
lbs/h: up to 772
of high quality dry ice pellets, depending on the extruder plate applied
Pellet Size:
Diameter:
mm: 3 - 10 or 16
inch: 0.11 - 0.39 or 0.62
Cylindrical - length varying from:
mm: 50 to 100 / inch: 1.96 to 3.93
Inlet Liquid CO
2
Pressure:
bar: 16 - 22
psi: 232 - 319
Liquid CO
2
Dryness Fraction:
The water content should not exceed 35 ppm and should not be less than 5 ppm – or equivalent to a dewpoint
temperature of -66°C to -51°C (-86.8°F to -59.8°F).
NOTE:
The liquid CO
2
supply must be completely free of oil and must have a purity of min. 99.9%.
Liquid CO
2
Supply Pipe:
Internal dia. 20 mm (0.8 inch), very well insulated with a minimum number of bends and fittings.
NOTE: If over 20 m (65.6 feet) in length, always use an internal dia. of 25 mm (1 inch).
Power Supply:
3 x 400 V AC + PE, 50Hz,
TN-S Earthing system
Imax. 32 A
480V AC Solidly Grounded Wye Source
3 Phase + GND wire, 60Hz
Imax. 32 A
Control Panel SCCR: 25kA rms symmetrical 480VAC Max.
Rated power:
16,6kW / 21,5 Hp
Machine Dimensions:
Length: 1500 / 59
Width: 1000 / 39
Height: 1800 / 71
Height: 1845 / 73.6 (incl. ext. legs)
Weight: 1150kg / 2535 lbs
Noise level: below 75 dB(a).
