IceTech PR350H - Page 210

DescriptionName
Holtec Automatic A/S
Agervigvej 46, Næsbjerg
68oo Varde
Tlf. +45 76767676 Fax. +45 76767677
e-mail: holtec@holtec.dk
Type EAN/EL/Order No.
Bill of Components
BECKHOFF EL9186-X201
-X202
-X203
-X1007
=G01-G1-TG1
=G01-Q1-K1
=G01-Q3-TG2
=G01-Q5-K2
=G01-TP1
=G02-G1-TG1
=G02-Q1-K1
=G02-Q3-TG2
=G02-Q5-K2
=G02-TP1
=HU01-C1-BL1
=HU01-C1-TT1
=HU01-G1-M1
=HU01-Q1-K01
=HU01-Q2-K01
=HU01-Q3-K01
=HU01-Q4-K01
=HU01-Q5-K01
=HU01-Q6-K01
=HU01-Q7-K01
=HU01-Q8-K01
=HU01-Q9-K01
=HU01-Q9-K02
=HU01-Q10-K01
=HU01-Q10-K02
=HU01-Q11-K01
=HU01-Q12-K01
BECKHOFF EL9187
BECKHOFF EL9187
230VAC Outlet
Solenoid valve 1 Extruder 1
Piston extruder 1
Die extruder 1
Pressure transmitter extruder 1 0-4bar/4-20mA
Solenoid valve 2 Extruder 1
Piston extruder 2
Die extruder 2
Solenoid valve 1 Extruder 2
Die extruder 2
Pressure transmitter extruder 2 0-4bar/4-20mA
Solenoid valve 2 Extruder 2
Electromagnetic level switch Hydraulic tank
Motor Hydraulic pump
Temperature transmitter hydraulic unit 0-100°C/4-20mA
Solenoid Hydraulic valve 1 Extruder 1
Solenoid Hydraulic valve 3 Extruder 1
Solenoid Hydraulic valve 2 Extruder 1
Solenoid Hydraulic valve 4 Extruder 1
Solenoid Hydraulic valve 6 Extruder 2
Solenoid Hydraulic valve 5 Extruder 2
Solenoid Hydraulic valve 7 Extruder 2
Solenoid Hydraulic valve 9 Extruder 1
Solenoid Hydraulic valve 8 Extruder 2
Solenoid Hydraulic valve 9 Extruder 1
Solenoid Hydraulic valve 10 Extruder 2
Solenoid Hydraulic valve 10 Extruder 2
Solenoid Hydraulic valve 11 Bypass
Solenoid Hydraulic valve 11 Bypass
Project titel: 11kW Dryice Pelletizer PR350
Case No.: PR750H / PR350H
Page 55 of56
Last Print: 1/6/2011 3:50:56 PM
Last Change: 10/20/2011
Customer: IceTech A/S
Page Title: Bill of Components
Project rev.:
Page rev.:
Number of Pages: 73
PC|SCHEMATIC Automation Fil navn: F:\Projekt\Ice-Tech\2011\IT1103 PR350H\Documentation\PDF\IT1103
=HU01-TP1 Pressure transmitter hydraulic unit 0-200bar/4-20mA
EL9186
0VDC DISTRIBUTION
0VDC DISTRIBUTION
Gewiss GW96514
Balluf BTL7-E10-M0350-B-S 32
Danfoss 018F6801
Balluf BTL7-E10-M0350-B-S 32
Danfoss 018F6801
Endress+Hauser PMP131-A4401A1Q
Balluf BTL7-E10-M0350-B-S 32
Danfoss 018F6801
Balluf BTL7-E10-M0350-B-S 32
Danfoss 018F6801
Endress+Hauser PMP131-A4401A1Q
AVN LM1-CTPA 175 NA
AVN 666680
3x400/690VAC D/Y P=11kW I=21,7A
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
ADC3E16EM 001
AVN MBS 33 060 G 1756
EL9186
500260
500260
