Procedures for maintenance and repair
www.icetechworld.com | IceTech Dry Ice Technology | Rev 1
Page 4
Procedure no. 1 Replacement of liquid CO2 filter + gasket
Disassembling the CO2 filter housing
Remove the filter housing by loosening the 4 screws [1] and pull the filter housing end plate
[2], gasket [3], filter [4] out wards. Replace the gasket if necessary [3] and the filter [4], and
assemble the filter housing endplate on the filter housing. The screws [1] are to be tightened
firmly and equally.
Notice!
It is very important to be careful and not get any dust or dirt into the filter housing under this
operation; this could block the Danfoss solenoid valves.
1
2
3
4
