Procedures for maintenance and repair
www.icetechworld.com | IceTech Dry Ice Technology | Rev 1
Page 8
Procedure no. 2 Replacement of degassingfilter + gasket
Disassembling the degassing sleeves
Remove the filter housing by loosening the 8 screws [5] and pull the filter housing [1], rubber
gasket [2], filter [3] and filter gasket [4] out wards. Replace the gaskets [2, 4] and the filter
[3], and assemble the filter housing on the extruder cylinder. The screws [5] are to be
tightening equally, and not so tight that rubber gasket is broken.
Notice! The screws [5] have different lengths. It’s important that the screws are not switched
as they will block and damage the extruder.
At production startup, it’s important to check if the degassing sleeves are tightened correctly.
1
2
3
4
5
