Procedures for maintenance and repair
www.icetechworld.com | IceTech Dry Ice Technology | Rev 1
Page 44
Procedure no. 10 Replacement of Danfoss EV3/EV15 Valves.
Disassembling and replace a Danfoss EV15 valve and solenoid
Remove the pipe by loosening the 2 flare nuts [1] dismount the plug on the solenoid and pull
of the solenoid [2], loosen the flare nut on this pipe [3], remove the EV15 valve [4. Replace
the EV15 valve and solenoid if needed. The flare nuts [1, 3] are to be tightened firmly check
that there are no leaks by the connections.
Notice! It is very important to be careful and not get any dust or dirt into the valve or pipes
under this operation; this could block the Danfoss solenoid valves.
1
2
3
4
