iCharger 1010B - Unpack Inspection; External Controls and Connections

-3-
iCharger
Synchronous Balance Charger/Discharger 1010B/106B
Unpack inspection
The following items are included in the package. Contact your supplier if any items are missing.
Standard items ：
：：
：
 One copy of the User’s manual
 One pair of output alligator clip leads
 One pair of input alligator clips (30A) and input leads with 4mm bullet connectors
 One temperature sensor lead (0 – 99 ℃ (210
o
F))
Optional items:
 Flexible silicone insulated 14AWG output lead with T-shaped connector
 Balance expansion board
External controls and connections
1010B
106B
1. DC input 2. LCD screen 3. Function button 4. Cooling Fan 5. Temperature sensor port
6. Balance socket 7. Output port
①
①
③
③
②
②
④
④
⑥
⑦
⑦
⑥
⑤
⑤
