[TUNER UNIT]

C7 4610000740 TRIMMER ECV-1ZW 10X53T T

C8 4010000360 CERAMIC DD106 SL 181J 50V T

C9 4510005110 ELECTROLYTIC 16 MV 33 HC T

C10 4010000520 CERAMIC DD107-601 B 472K 50V T

C11 4020000990 CYLINDER UP050 B 473K-NA-CZ T

C12 4010000410 CERAMIC DD107 SL 331J 50V T

C13 4010000410 CERAMIC DD107 SL 331J 50V T

C14 4020000990 CYLINDER UP050 B 473K-NA-CZ T

C15 4020001000 CERAMIC RPER11H472K2P1A01B T

C16 4010000520 CERAMIC DD107-601 B 472K 50V T

C17 4020000980 CYLINDER UP050 B 104K-NA-CZ T

C18 4020000990 CYLINDER UP050 B 473K-NA-CZ T

C19 4020000420 CYLINDER UP050 SL 100J T

C20 4010000210 CERAMIC DD104 SL 300J 50V T

C21 4010000410 CERAMIC DD107 SL 331J 50V T

C22 4010000520 CERAMIC DD107-601 B 472K 50V T

C23 4020000990 CYLINDER UP050 B 473K-NA-CZ T

C24 4320000661 DIP MICA KD20C 122J5A T

C25 4320000661 DIP MICA KD20C 122J5A T

C26 4320000661 DIP MICA KD20C 122J5A T

C28 4010004740 CERAMIC DE1207 SL 271J 2KV T

C29 4010004750 CERAMIC DE1510 SL 331J 2KV T

C30 4010004280 CERAMIC DE1207 SL 151J 3KV T

C31 4010004280 CERAMIC DE1207 SL 151J 3KV T

C32 4010004280 CERAMIC DE1207 SL 151J 3KV T

C34 4010000520 CERAMIC DD107-601 B 472K 50V T

C35 4010004280 CERAMIC DE1207 SL 151J 3KV T

C36 4010004280 CERAMIC DE1207 SL 151J 3KV T

C37 4010004790 CERAMIC

DEC1X3J680JC4B (DE1210SL680J)

C38 4010004260 CERAMIC DE0907 SL 820J 3KV T

C39 4010004770 CERAMIC

DEC1X3J390JC4B (DE0910SL390J)

C40 4010004770 CERAMIC

DEC1X3J390JC4B (DE0910SL390J)

C41 4010005040 CERAMIC DE0707 SL 180J 3KV T

C42 4010005040 CERAMIC DE0707 SL 180J 3KV T

C43 4010000520 CERAMIC DD107-601 B 472K 50V T

C44 4010004810 CERAMIC

DEC1X3J101JC4B (DE1310SL101J)

C45 4010004810 CERAMIC

DEC1X3J101JC4B (DE1310SL101J)

C46 4010004810 CERAMIC

DEC1X3J101JC4B (DE1310SL101J)

C47 4010004810 CERAMIC

DEC1X3J101JC4B (DE1310SL101J)

C48 4010000520 CERAMIC DD107-601 B 472K 50V T

C50 4020000980 CYLINDER UP050 B 104K-NA-CZ T

C52 4010000520 CERAMIC DD107-601 B 472K 50V T

C53 4510003900 ELECTROLYTIC 16 MV 22 HW T

C54 4010000520 CERAMIC DD107-601 B 472K 50V T

C55 4010000520 CERAMIC DD107-601 B 472K 50V T

C56 4510005120 ELECTROLYTIC 16 MV 47 HC T

C57 4010000520 CERAMIC DD107-601 B 472K 50V T

C58 4010000520 CERAMIC DD107-601 B 472K 50V T

C59 4020000990 CYLINDER UP050 B 473K-NA-CZ T

C60 4510004590 ELECTROLYTIC 16 MV 470 HC T

C61 4010000520 CERAMIC DD107-601 B 472K 50V T

C62 4010000520 CERAMIC DD107-601 B 472K 50V T

C64 4010000520 CERAMIC DD107-601 B 472K 50V T

C65 4010000520 CERAMIC DD107-601 B 472K 50V T

C66 4010000520 CERAMIC DD107-601 B 472K 50V T

C68 4020001000 CERAMIC RPER11H472K2P1A01B T

C69 4010000500 CERAMIC DD104 B 102K 50V T

C70 4010000520 CERAMIC DD107-601 B 472K 50V T

C71 4010000520 CERAMIC DD107-601 B 472K 50V T

C72 4020001000 CERAMIC RPER11H472K2P1A01B T

C73 4020001000 CERAMIC RPER11H472K2P1A01B T

C74 4010000520 CERAMIC DD107-601 B 472K 50V T

C75 4310000520 MYLAR 50 F2D 224J T

C76 4010000520 CERAMIC DD107-601 B 472K 50V T

C77 4010000520 CERAMIC DD107-601 B 472K 50V T

C78 4010000430 CERAMIC DD108-601 SL 471J 50V T

C79 4010000460 CERAMIC DD104 B 471K 50V T

C81 4020001000 CERAMIC RPER11H472K2P1A01B T

C82 4550000340 TANTALUM DN 1C 100M T

C83 4510005460 ELECTROLYTIC FYDOH 474Z T

C84 4310000520 MYLAR 50 F2D 224J T

C85 4310000520 MYLAR 50 F2D 224J T

C86 4010000500 CERAMIC DD104 B 102K 50V T

C87 4010000810 CERAMIC DD104 CH 300J 50V T

C88 4010000810 CERAMIC DD104 CH 300J 50V T

C89 4020001000 CERAMIC RPER11H472K2P1A01B T

C90 4530000250 ARRAY B8XC0112-33N T

C91 4010000520 CERAMIC DD107-601 B 472K 50V T

C92 4020001000 CERAMIC RPER11H472K2P1A01B T

C93 4530000250 ARRAY B8XC0112-33N T

C94 4010000520 CERAMIC DD107-601 B 472K 50V T

C95 4010000520 CERAMIC DD107-601 B 472K 50V T

C96 4530000250 ARRAY B8XC0112-33N T

C98 4010000520 CERAMIC DD107-601 B 472K 50V T

C100 4010000520 CERAMIC DD107-601 B 472K 50V T

C102 4010000520 CERAMIC DD107-601 B 472K 50V T

C104 4010000520 CERAMIC DD107-601 B 472K 50V T

C106 4010000520 CERAMIC DD107-601 B 472K 50V T

S.=Surface mount

5 - 3

REF ORDER

DESCRIPTION M.

NO. NO.

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

[TUNER UNIT]

C108 4010000520 CERAMIC DD107-601 B 472K 50V T

C110 4010000520 CERAMIC DD107-601 B 472K 50V T

C112 4010000520 CERAMIC DD107-601 B 472K 50V T

C114 4010000520 CERAMIC DD107-601 B 472K 50V T

C116 4010000520 CERAMIC DD107-601 B 472K 50V T

C118 4010000520 CERAMIC DD107-601 B 472K 50V T

C120 4010000520 CERAMIC DD107-601 B 472K 50V T

C122 4010000520 CERAMIC DD107-601 B 472K 50V T

C124 4010000520 CERAMIC DD107-601 B 472K 50V T

C126 4010000520 CERAMIC DD107-601 B 472K 50V T

C128 4010000520 CERAMIC DD107-601 B 472K 50V T

C130 4010000520 CERAMIC DD107-601 B 472K 50V T

C132 4010000520 CERAMIC DD107-601 B 472K 50V T

C134 4010000520 CERAMIC DD107-601 B 472K 50V T

C136 4010000520 CERAMIC DD107-601 B 472K 50V T

C137 4530000250 ARRAY B8XC0112-33N T

C138 4530000250 ARRAY B8XC0112-33N T

C139 4530000250 ARRAY B8XC0112-33N T

C140 4530000250 ARRAY B8XC0112-33N T

C141 4530000250 ARRAY B8XC0112-33N T

C142 4530000250 ARRAY B8XC0112-33N T

C144 4530000050 ARRAY B5RC0126-33N T

C147 4010000520 CERAMIC DD107-601 B 472K 50V T

C148 4020001000 CERAMIC RPER11H472K2P1A01B T

C150 4010000520 CERAMIC DD107-601 B 472K 50V T

C152 4010000520 CERAMIC DD107-601 B 472K 50V T

C153 4010000520 CERAMIC DD107-601 B 472K 50V T

C155 4010000520 CERAMIC DD107-601 B 472K 50V T

C156 4020001000 CERAMIC RPER11H472K2P1A01B T

C162 4010005610 CERAMIC

HM60SJ SL 100D 500 V [AT-130E]

4010005660 CERAMIC HM60SJ SL 220J 500V [OTHER] T

C163 4020001000 CERAMIC RPER11H472K2P1A01B T

C164 4010000520 CERAMIC DD107-601 B 472K 50V T

C165 4010000520 CERAMIC DD107-601 B 472K 50V T

C166 4530000250 ARRAY B8XC0112-33N T

C167 4530000250 ARRAY B8XC0112-33N T

C168 4530000250 ARRAY B8XC0112-33N T

C169 4010000520 CERAMIC DD107-601 B 472K 50V T

C170 4020001000 CERAMIC RPER11H472K2P1A01B T

C171 4010000520 CERAMIC DD107-601 B 472K 50V T

C172 4010000520 CERAMIC DD107-601 B 472K 50V T

C173 4010000520 CERAMIC DD107-601 B 472K 50V T

C174 4020000990 CYLINDER UP050 B 473K-NA-CZ T

C175 4020001000 CERAMIC RPER11H472K2P1A01B T

C176 4010000520 CERAMIC DD107-601 B 472K 50V T

C177 4020001000 CERAMIC RPER11H472K2P1A01B T

C178 4010000520 CERAMIC DD107-601 B 472K 50V T

C179 4010000520 CERAMIC DD107-601 B 472K 50V T

C181 4020001000 CERAMIC RPER11H472K2P1A01B T

C182 4010003930 CERAMIC DD06 SL 270K 500V T

RL1 6330001070 RELAY AJQ1341 B01 T

RL2 6330001070 RELAY AJQ1341 B01 T

RL3 6330001060 RELAY APQ 3311 T

RL4 6330000570 RELAY AR-39251 T

RL5 6330001060 RELAY APQ 3311 T

RL6 6330001060 RELAY APQ 3311 T

RL7 6330001060 RELAY APQ 3311 T

RL8 6330001060 RELAY APQ 3311 T

RL9 6330001060 RELAY APQ 3311 T

RL10 6330001060 RELAY APQ 3311 T

RL11 6330001060 RELAY APQ 3311 T

RL12 6330001060 RELAY APQ 3311 T

RL13 6330001060 RELAY APQ 3311 T

RL14 6330001060 RELAY APQ 3311 T

RL15 6330001060 RELAY APQ 3311 T

RL16 6330001060 RELAY APQ 3311 T

RL17 6330001060 RELAY APQ 3311 T

RL18 6330001060 RELAY APQ 3311 T

RL19 6330001060 RELAY APQ 3311 T

RL20 6330001060 RELAY APQ 3311 T

RL21 6330001060 RELAY APQ 3311 T

RL22 6330001060 RELAY APQ 3311 T

RL23 6330001060 RELAY APQ 3311 T

RL24 6330001060 RELAY APQ 3311 T

RL25 6330000570 RELAY AR-39251 T

RL26 6330000570 RELAY AR-39251 T

RL27 6330000570 RELAY AR-39251 T

J1 6510000130 CONNECTOR FM MDR MI [AT-130/E] only T

J4 6910003140 CONNECTOR IMSA-9202B-1-02T T

J5 6910003140 CONNECTOR IMSA-9202B-1-02T T

J6 6910003140 CONNECTOR IMSA-9202B-1-02T T

J8 6510024500 CONNECTOR B06B-XH-A T

J9 6510015150 CONNECTOR ML-800S1V-6P [AT-130/E] only T

J13 6910003140 CONNECTOR IMSA-9202B-1-02T T

REF ORDER

DESCRIPTION M.

NO. NO.
