Icom AT-140 Service Manual

1 - 1
SECTION 1 SPECIFICATIONS
‘‘
GENERAL
• Number of memory channels : 45
• Frequency range : 1.6 MHz to 30 MHz with a 7 m (23 ft) or longer antenna element
• Maximum input power : 150 W PEP
100 W continuous
• Input impedance : 50 Ω
• Minimum operating input power : 5 to 15 W
• Automatic tuning time :
(General) Approx. 2 to 3 sec. (max. 15 sec.)
(Returning to a memorized frequency) Approx. 1 sec.
• Tuning accuracy (VSWR) : Less than 2.0 : 1
(after tuning; except for multiples of
1
⁄2 λ)
• Antenna required : Marconi-type with suitable RF ground
(More than 7 m (23 ft) is suggested)
• Power supply required : DC 13.6 V ± 15 % (supplied from HF transceiver)
• Current drain : Less than 2 A
• Usable temperature range : –30˚C to +60˚C; –22˚F to +140˚F
• Dimensions
(projections not included) : 230(W) × 80(H) × 340(D) mm
9
3
⁄32(W) × 3
3
⁄32(H) × 13
13
⁄32(D) in
• Case construction : Weatherproof
• Weight :
(AT-130/AT-140) Approx. 2.5 kg; 5 lb 8 oz
(AT-130E) Approx. 2.7 kg; 6 lb
• Control cable : OPC-420 (For [IC-77/78])
OPC-566 (For [IC-M700PRO], [IC-M710/RT])
OPC-1147 (For [IC-M802])
OPC-1186 (For [IC-F7000])
All stated specifications are subject to change without notice or obligation.

Icom AT-140 Specifications

General

Compatibility	IC-M802
Product color	Gray
Frequency range	1.6 - 30 MHz
Brand compatibility	ICOM
Quantity	1
