[TUNER UNIT]
WS1 8970020241 OTHER EX1157 J BOARD SET-1 (10)/TU T
WS2 8600030510 OTHER EX1157 J03TU [OTHER] T
8970020250 OTHER EX1157 J LEAD SET (3) /TU
[AT-130E] T
WS3 8600030510 OTHER EX1157 J03TU [AT-130E] T
8600030520 OTHER EX1157 J02TU [OTHER] T
WS4 8600030520 OTHER EX1157 J02TU [AT-130E] T
8970020260 OTHER EX1157 J LEAD SET (2) /TU
[OTHER] T
WS5 8600030530 OTHER EX1157 P01TU [AT-130E] T
EP1 0910037487 PCB B 3678G
EP2 9030602001 TUBE IRRAX 1 (d) L=10 mm T
EP3 9029403902 TUBE IRRAX 1 (d) L=5 mm T
EP4 0910037981 PCB B 3758A [AT-130/E] only
D301 1710000030 DIODE 1S1555 T
D302 1710000030 DIODE 1S1555 T
D303 1710000030 DIODE 1S1555 T
D304 1710000030 DIODE 1S1555 T
D305
1710000021
DIODE
1N60 <AMI>
T
L302 6110002870 COIL LA-473 T
L303 6110002870 COIL LA-473 T
L304 6110002870 COIL LA-473 T
L305 6110002870 COIL LA-473 T
L306 6110002870 COIL LA-473 T
L307 6110002870 COIL LA-473 T
L308 6110002870 COIL LA-473 T
L309 6110002870 COIL LA-473 T
L310 6110002870 COIL LA-473 T
L311 6110002870 COIL LA-473 T
L312 6110002870 COIL LA-473 T
L313 6110002870 COIL LA-473 T
L314 6110002870 COIL LA-473 T
L315 6110002870 COIL LA-473 T
L316 6110002870 COIL LA-473 T
L317 6110002880 COIL LA-474 T
L319 6140001550 COIL LR-174 T
L320 6910000670 COIL BL01RN1A1D2B (BL01RN1-A62) T
L321 6910000670 COIL BL01RN1A1D2B (BL01RN1-A62) T
R301 7010001000 RESISTOR R25XJ 56 Ω T
R302 7010001000 RESISTOR R25XJ 56 Ω T
R303 7010001000 RESISTOR R25XJ 56 Ω T
R304 7010000940 RESISTOR R25XJ 18 Ω T
R305 7010001340 RESISTOR R25XJ 33 kΩ T
R306 7070000341 RESISTOR ERG1SJ 330 (33 Ω)T
C301 4010000520 CERAMIC DD107-601 B 472K 50V T
C302 4010000520 CERAMIC DD107-601 B 472K 50V T
C303 4010000520 CERAMIC DD107-601 B 472K 50V T
C304 4010000520 CERAMIC DD107-601 B 472K 50V T
C305 4010000520 CERAMIC DD107-601 B 472K 50V T
C306 4010000420 CERAMIC DD107-601 SL 391J 50V T
C309 4320000661 DIP MICA KD20C 122J5A T
C310 4320000681 DIP MICA KD19C 681J5A T
C311 4320000651 DIP MICA KD20C 102J5A T
C312 4010004260 CERAMIC DE0907 SL 820J 3KV
T
C313 4010004260 CERAMIC DE0907 SL 820J 3KV T
C314 4010004260 CERAMIC DE0907 SL 820J 3KV T
C315 4010004250 CERAMIC DE1007 SL 101J 3KV T
C316 4010004250 CERAMIC DE1007 SL 101J 3KV T
C317 4010004250 CERAMIC DE1007 SL 101J 3KV T
C318 4010004290 CERAMIC DE1310 SL 181J 3KV T
C319 4010004290 CERAMIC DE1310 SL 181J 3KV T
C320 4010005010 CERAMIC DE1105 SL 331J 1KV T
C321 4010005080 CERAMIC
DEA1X3F470JC3B (DE0707SL470J)
T
RL301 6330000840 RELAY G2R-1 DC12V T
RL302 6330000840 RELAY G2R-1 DC12V T
RL303 6330000840 RELAY G2R-1 DC12V T
S.=Surface mount
5 - 5
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MANUAL UNIT]
RL304 6330000570 RELAY AR-39251 T
J301 6510002250 CONNECTOR TL25P03V1 T
J302 6910003160 CONNECTOR IMSA-9202B-2-08T T
J303 6510003100 CONNECTOR RT01T-1.3B T
J305 6510003100 CONNECTOR RT01T-1.3B T
J307 6510006600 CONNECTOR RT01N-2.3A T
J308 6510006600 CONNECTOR RT01N-2.3A T
J309 6510006600 CONNECTOR RT01N-2.3A T
J310 6510006600 CONNECTOR RT01N-2.3A T
J311 6510006600 CONNECTOR RT01N-2.3A T
J312 6510006600 CONNECTOR RT01N-2.3A T
J313 6510006600 CONNECTOR RT01N-2.3A T
J314 6510006600 CONNECTOR RT01N-2.3A T
J315 6510006600 CONNECTOR RT01N-2.3A T
J316 6510006600 CONNECTOR RT01N-2.3A T
J317 6510006600 CONNECTOR RT01N-2.3A T
J318 6510006600 CONNECTOR RT01N-2.3A T
J319 6510006600 CONNECTOR RT01N-2.3A T
J320 6510006600 CONNECTOR RT01N-2.3A T
J321 6510006600 CONNECTOR RT01N-2.3A T
J322 6510006600 CONNECTOR RT01N-2.3A T
J323 6510006600 CONNECTOR RT01N-2.3A T
P301 6910003120 CONNECTOR IMSA-9206H-T T
P302 6910003120 CONNECTOR IMSA-9206H-T T
P303 6910003120 CONNECTOR IMSA-9206H-T T
P304 6910003120 CONNECTOR IMSA-9206H-T T
W304 9054500720 WIRE 76/98/040/X98/X98 T
WS1 8970020270 OTHER EX1157 J LEAD SET (3) /MN T
WS2 8600030540 OTHER EX1157 P305MN T
EP301 0910015134 PCB B 1238D
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
[MANUAL UNIT] ([AT-130E] ONLY)
