Icom IC-718 - Page 17

5 - 5
CP4002
Ic APC pre-setting
J3601
Idling current
pre-setting
R1707
Output power
adjustment
L151
Tx total gain
adjustment
L106
R503
L501
L303
L302
L301
R1720
Ic APC
adjustment
R2701
Tx total gain
pre-setting
R21
Idling current
adjustment
(Driver)
R24
Idling current
adjustment
(Final)
J5
SWR detector
check point
J4
SWR detector
pre-setting
C17
SWR detector
adjustment
• PA unit • FILTER unit
• MAIN unit
