SECTION 1
SPECIFICATIONS
All stated specifi cations are typical and subject to change without notice or obligation.
■ General
• Frequency coverage : (unit: MHz)
Receive
0.030–60.000*
1
*
2
Transmit
1.800–1.999*
2
, 3.500–3.999*
2
,
5.330500*
3
, 5.346500*
3
, 5.366500*
3
,
5.371500*
3
, 5.403500*
3
,
7.000–7.300*
2
, 10.100–10.150*
2
,
14.000–14.350*
2
, 18.068–18.168*
2
,
21.000–21.450*
2
, 24.890–24.990*
2
,
28.000–29.700*
2
,
50.000–54.000*
2
*
1
Some frequency bands are not guaranteed.
*
2
Depending on version. *
3
Only USA version.
• Mode : USB, LSB, CW, RTTY, AM, FM
• No. of memory channels : 101CH
( 99 regular, 2 scan edges)
• Antenna impedance : 50 Ω ( at Antenna Tuner OFF)
• Antenna connector type : SO-239 × 2
•
Usable temperature range
: 0˚C to +50˚C (+32˚F to +122˚F)
• Frequency stability : Less than ±0.5 ppm 5 min. after
power ON.
(0˚C to +50˚C; +32˚F to
+122˚F)
• Frequency resolution : 1 Hz
• Power supply :
13.8 V DC ±15% (negative ground)
• Power consumption
Transmit
Max. power : 23.0 A
Receive
Standby : 2.2 A
Max. audio : 3.0 A
• Dimensions : 315(W) × 116(H) × 343(D) mm
(projections not included) 12.4(W) × 4.57(H) × 13.5(D) in
• Weight (approx.) : 10.2 kg; 22.4 lb
• ACC connector : 13-pin
• CI-V connector : 2-conductor 3.5 (d) mm (
1
⁄
8
″)
■ Transmitter
• Output power (continuously adjustable)
SSB/CW/RTTY/FM : 2 to 100 W
AM : 2 to 27 W*
(*Carrier power)
(at 13.8 V DC/+25˚C)
• Modulation system
SSB : Digital PSN modulation
AM : Digital Low power modulation
FM : Digital Phase modulation
• Spurious emission
HF bands : Less than –50 dB
50 MHz band : Less than –63 dB
• Carrier suppression : More than 40 dB
• Unwanted sideband
suppression : More than 55 dB
•
TX variable range : ±9.999 kHz
• Microphone connector : 8-pin connector
(600 Ω)
• ELEC-KEY connector : 3-conductor 6.35(d) mm (
1
⁄
4
″)
• KEY connector : 3-conductor 6.35(d) mm (
1
⁄
4
″)
• SEND connector : Phono jack
(RCA)
• ALC connector : Phono jack (RCA)
■ Receiver
• Receive system :
Double superheterodyne system
• Intermediate frequencies
1st : 64.455 MHz
2nd : 36 kHz
• Sensitivity
SSB, CW : 0.16 µV
(1.80–29.99 MHz)*
4
(10 dB S/N) BW=2.4 kHz 0.13 µV (50.0–54.0 MHz)*
5
AM (10 dB S/N) : 12.6 µV (0.5–1.799 MHz)*
4
BW=6 kHz 2.0 µV (1.80–29.99 MHz)*
4
1.6 µV (50.0–54.0 MHz)*
5
FM (12 dB SINAD) : 0.5 µV (28.0–29.7 MHz)*
4
BW=15 kHz 0.32 µV (50.0–54.0 MHz)*
5
• Squelch sensitivity
Frequency band Squelch sensitivity
HF
SSB : Less than 5.6 µV*
4
FM : Less than 0.32 µV*
4
50 MHz
SSB : Less than 5.6 µV*
5
FM : Less than 0.32 µV*
5
*
4
Preamp 1 is ON. *
5
Preamp 2 is ON.
• Selectivity (IF fi lter shape is set to SHARP.)
SSB
(BW: 2.4 kHz) : More than 2.4 kHz/–6 dB
Less than 3.4 kHz/–40 dB
CW
(BW: 500 Hz) : More than 500 Hz/–6 dB
Less than 700 Hz/–40 dB
RTTY
(BW: 350 Hz) : More than 500 Hz/–6 dB
Less than 800 Hz/–40 dB
AM
(BW: 6 kHz) : More than 6.0 kHz/–6 dB
Less than 10.0 kHz/–40 dB
FM
(BW: 15 kHz) : More than 12.0 kHz/–6 dB
Less than 22.0 kHz/–40 dB
• Spurious and image rejection ratio
: More than 70 dB
• AF output power : More than 2.0 W at 10%
(at 13.8 V DC) distortion with an 8 Ω load
• RIT variable range : ±9.999 kHz
• PHONES connector :
3-conductor 6.35 (d) mm (
1
⁄
4
″)
• External SP connector : 2-conductor 3.5 (d) mm
(
1
⁄
8
″)/8 Ω
• DSP ANF attenuation : More than 30 dB
(with 1 kHz single tone)
• DSP MNF attenuation : More than 70 dB
• DSP NR attenuation : More than 6 dB
(noise rejection in SSB)
■ Antenna tuner
• Matching impedance range
HF bands : 16.7 to 150 Ω unbalanced
(Less than VSWR 1:3)
50 MHz band : 20 to 125 Ω unbalanced
(Less than VSWR 1:2.5)
• Minimum operating input : 8 W (HF bands)
power 15 W (50MHz band )
• Tuning accuracy : VSWR 1:1.5 or less
• Insertion loss
(after tuning at RF power 100W)
1.8 MHz band : 1.2 dB or less
Bands other than 1.8 MHz : 1.0 dB or less
To Next Page
