6 - 2
[RF-A UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J301* 6510020081 52808-2071 (2090) 1
J451* 6510019991 52808-2271 (2291) TAPING 1
J501* 6510007020 TMP-J01X-V6 1
J701* 6510007020 TMP-J01X-V6 1
J741* 6510007020 TMP-J01X-V6 1
J801* 6510007020 TMP-J01X-V6 1
J931* 6510027650 AXN480C330P 1
J951* 6510027660 AXN380C038P 1
J1011* 6510007020 TMP-J01X-V6 1
J1141* 6510007020 TMP-J01X-V6 1
J1301* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1
EP911* 6910002161 CASE-BM7H-LF 1
EP913* 6910002161 CASE-BM7H-LF 1
MP651* 8510012400 2177 D/A CASE Y454 1
MP911* 8930065741 2590 D-EARTH SPRING-1 1
MP1071
* 6910001130 10MSHIELD CASE (P10L-A) 1
MP1101
* 8510012400 2177 D/A CASE Y454 1
MP1121
* 8510015900 2590 M-2LO CASE Y697 1
MP1201
* 8510012400 2177 D/A CASE Y454 1
MP1701
* 8510010760 1876 DDS CASE 1
MP1702
* 8510010770 1876 DDS COVER 1
[BPF UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J141* 6510007020 TMP-J01X-V6 1
J201* 6510007020 TMP-J01X-V6 1
J301* 6510007020 TMP-J01X-V6 1
J302* 6510020081 52808-2071 (2090) 1
MP31* 8930062740 2590 M-SPRING 1
[PA-A UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J201* 6510007020 TMP-J01X-V6 1
J401* 6510020081 52808-2071 (2090) 1
J402* 6510020051 B11B-PH-SM4-TB (LF) (SN) 1
J451* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1
J462* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J1201* 6510007020 TMP-J01X-V6 1
F1* 5220000400 FHA010-01F 1
F2* 5210001050 ICP-S0.5TN 1
F3* 5210000940 1205 1
EP1* 6910020710 OT-047 M3 1
EP2* 6910020710 OT-047 M3 1
MP131* 8510020100 3182 DC-DC CASE Y1220 1
MP132* 8930082270 3182 DC-DC PLATE Y1221 1
[CTRL UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510007020 TMP-J01X-V6 1
J301* 6510007020 TMP-J01X-V6 1
J351* 6510007020 TMP-J01X-V6 1
J901* 6510020081 52808-2071 (2090) 1
J1001* 6510022031 B10B-ZR-SM4-TF (LF) (SN) 1
J1101* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J1201* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J2101* 6510007020 TMP-J01X-V6 1
W2001* 7030012280 RD25T0R0 1
W2002* 7030012280 RD25T0R0 1
MP401* 8930065741 2590 D-EARTH SPRING-1 1
MP601* 8510002020 MIXSHIELD CASE SX155 1
MP701* 8510018851 2355 A-SHIELD CASE-1 Y1086A 1
MP702* 8510002280 VCOSHIELD (A) FX 15 1
[NETWORK UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1 6510007020 TMP-J01X-V6 1
J91 6510007020 TMP-J01X-V6 1
J201* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
MF1 2710000800 MP24ZA (STEPPING MOTOR) 1
MF2 2710000800 MP24ZA (STEPPING MOTOR) 1
MP1 8930041091 1876 A-ANGLE-1 1
MP2 8810008661 PHBT M3 X 8 NI-ZC3 1
MP3 8810009061 FLAT M3 X 6 ZK3 4
MP4 8930041111 1876 B-ANGLE-1 1
MP5 8810009061 FLAT M3 X 6 ZK3 2
MP6 8820000881 1528 SCREW-1 4
MP7 8930030112 1414 PLATE-2 2
MP8 8950003200 UJ6-5 (UNIVERSAL COUPPLING) 2
MP9* 8930051580 2178 TUNER PLATE Y503 1
[FRONT UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
W1 8900019300 OPC-2032 (P1N6L50) 1
W2 8900018000 OPC-1344A (P1N10L70) 1
W3 8900018000 OPC-1344A (P1N10L70) 1
W4 8900018000 OPC-1344A (P1N10L70) 1
W5 8900019300 OPC-2032 (P1N6L50) 1
W6 8900019300 OPC-2032 (P1N6L50) 1
W7 8900019300 OPC-2032 (P1N6L50) 1
EP1 0880002940 EX-2500 #04 SENSOR 1
EP2 6910015650 S-G2218-3#01 (MOUNT PLATE) 0 1
EP3 6910015650 S-G2218-3#01 (MOUNT PLATE) 0 1
MP1 8210026220 3183 FRONT PANEL (A)ASSEMBLY 1
MP2 8010021650 3183 SUB CHASSISASSEMBLY 1
MP4 8310076250 3183 WINDOW PLATE (A) 1
MP5 8930080710 3183 KEYBOARD (A) (SHJ) 1
MP6 8610014220 KNOB K-295 (A) 1
MP7 8610014050 KNOB K-294 1
MP9 8610014090 KNOB K-293 1
MP10 8610014020 KNOB K-290 1
MP11 8610014200 KNOB K-291 (A) 1
MP12 8610014210 KNOB K-292 (A) 1
MP13 8610014110 KNOB N-379 (A) 1
MP14 8610014230 KNOB K-297 (A) 1
MP15 8610014240 KNOB K-296 (A) 1
MP16 8610014100 KNOB N-378 (A) 4
MP18 8610013922 KNOB N-268ASSEMBLY (A)-2 1
MP20 8930076900 3073 D-RUBBER (TOP) 1
MP27 8930076910 3073 BRAKE BUTTON 1
MP28 8930077360 3073 BRAKE PAD 2
MP29 8610011830 KNOBN301 1
MP30 8610013290 KNOB N-361 4
MP31 8610014140 KNOB N-380ASSEMBLY (A) 1
MP32 8810008761 PHBT M2 X 8 NI-ZC3 17
MP34 8810008661 PHBT M3 X 8 NI-ZC3 10
MP35 8930081070 3183 WINDOW SHEET 1
MP37 8930074940 SPONGE (JY) 1
MP38 8930082280 SPONGE (LB) 1
MP39 8930082260 SPONGE (LA) 1
MP40 8930082260 SPONGE (LA) 1
MP41 8930082320 SPONGE (LC) 1
MP42 8930082320 SPONGE (LC) 1
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
