Icom IC-7610

D Command formats (Continued)
• Data mode with lter width settings
Command: 1A 06
• IF lter width settings
Command: 1A 03
• AGC time constant settings
Command: 1A 04
• SSB transmission passband width settings
Command: 1A 05 0015, 05 0016, 05 0017
q
X X X X
w
01=FIL1
02=FIL2
03=FIL3
00=Data mode OFF*
01=DATA1
02=DATA2
03=DATA3
*
When 00 is set, also set 00 to w
Mode Data Steps
SSB/CW/
RTTY/PSK
0 to 9 50 ~ 500 Hz (50 Hz)
SSB/CW/
PSK
10 to 40 600 Hz ~ 3.6 kHz (100 Hz)
RTTY 10 to 31 600 ~ 2.7 kHz (100 Hz)
AM 0 to 49 200 Hz ~ 10.0 kHz (200 Hz)
Data
AGC time constant (sec.)
SSB/CW/RTTY/PSK AM
0
OFF OFF
1 0.1 0.3
2 0.2 0.5
3 0.3 0.8
4 0.5 1.2
5 0.8 1.6
6 1.2 2.0
7 1.6 2.5
8 2.0 3.0
9 2.5 4.0
10 3.0 5.0
11 4.0 6.0
12 5.0 7.0
13 6.0 8.0
XX
Higher edge: 0= 2500 Hz
1= 2700 Hz
2= 2800 Hz
3= 2900 Hz
Lower edge: 0= 100 Hz
1= 200 Hz
2= 300 Hz
3= 500 Hz
• RX HPF/LPF setting for each operating mode
Command: 1A 05 0001, 05 0004, 05 0007,
05 0010, 05 0011, 05 0012
X X X X
LPF (Upper edge)
HPF (Lower edge)
*The value of the HPF should be smaller than the LPF.
HPF
00: Through
01 ~ 20: 100 ~ 2000 Hz
LPF
05 ~ 24: 500~2400 Hz
25: Through
• Bandscope edge frequency settings
Command: 1A 05 0182 ~ 05 0217
1 kHz: 0–9 100 Hz: 0 (fixed) 100 kHz: 0–9 10 kHz: 0–9 10 MHz: 0–6 1 MHz: 0–9 1 kHz: 0–9 100 Hz: 0 (fixed) 100 kHz: 0–9 10 kHz: 0–9 10 MHz: 0–6 1 MHz: 0–9
q
X 0 X X X X X 0 X X X X
w e r t y
Lower edge Higher edge
• Color settings
Command: 1A 05 0172, 0173, 0174, 0219, 0221,
0234, 0243, 0244, 0245, 0246,
0250, 0255, 0256, 0257, 0258
q
0 XXX0XXX0 XXX
werty
R (Red)
0000 ~ 0255
G (Green)
0000 ~ 0255
B (Blue)
0000 ~ 0255
• Offset frequency settings
Command: 1A 05 0035, 0036, 0040
1 kHz digit: 0–9 100 Hz digit: 0 (fixed) 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9*
2
1 MHz digit: 0–9 Direction: 00=+ direction 01=– direction
q
0X X X X XX
w e
0
r*
1
*1 No need to enter for transverter offset frequency setting.
*2
Transverter offset only. Fix to ‘0’ for split offset setting.
Remote control
12
