*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to
“
GENERAL WIRING
”
for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head NI: Nickel ZU: Zinc SUS: Stainless
REF PART
DESCRIPTION QTY.
NO. NO.
REF PART
DESCRIPTION QTY.
NO. NO.
[RF UNIT]
[DIGISEL-A UNIT]
REF PART
DESCRIPTION QTY.
NO. NO.
[DIGISEL-B UNIT]
J1001* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1002* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1071* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1072* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1091* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1101* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1102* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1171* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1172* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1191* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1301* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J1401* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J2001* 6510032230 40P9.0-JMCS-G-B-TF (N) 1
J2002* 6510032240 50P9.0-JMCS-G-B-TF (N) 1
J2481* 6510028210 SJ050010 (TMP-J01X-V6) 1
J3001* 6510032230 40P9.0-JMCS-G-B-TF (N) 1
J3002* 6510032240 50P9.0-JMCS-G-B-TF (N) 1
J3481* 6510028210 SJ050010 (TMP-J01X-V6) 1
J4001* 6450002520 RL-1515-2 (B.B)-L 1
J4002* 6510023730 LGY6502-0600C 1
J4003* 6510023730 LGY6502-0600C 1
J4004* 6510031660 LGR4609-7100F 1
J4005* 6510023730 LGY6502-0600C 1
J4006* 6510023671 TCS4480-0141577 1
J4007* 6510023661 TCS4470-0141577 1
J4051* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1* 6510028210 SJ050010 (TMP-J01X-V6) 1
J2* 6510028210 SJ050010 (TMP-J01X-V6) 1
J2017* 6510019971 52808-1071 1
J2018* 6510003391 B3B-EH-S (LF) (SN) 1
MP1* 8930062740 2590 M-SPRING 1
MP2* 8930062740 2590 M-SPRING 1
MP3* 8930062740 2590 M-SPRING 1
MP4* 8930062740 2590 M-SPRING 1
MP5* 8930062740 2590 M-SPRING 1
MP8 8510018460 3009 DIGISEL CASE 1
MP9 8510018470 3009 DIGISEL COVER 1
MP14 8810007231 SET SCREWH M3×8 ZC3 7
MP15 8810007231 SET SCREWH M3×8 ZC3 6
J1* 6510028210 SJ050010 (TMP-J01X-V6) 1
J2* 6510028210 SJ050010 (TMP-J01X-V6) 1
J2017* 6510019971 52808-1071 1
J2018 6510003391 B3B-EH-S (LF) (SN) 1
MP1* 8930062740 2590 M-SPRING 1
MP2* 8930062740 2590 M-SPRING 1
MP3* 8930062740 2590 M-SPRING 1
MP4* 8930062740 2590 M-SPRING 1
MP5* 8930062740 2590 M-SPRING 1
MP8 8510018460 3009 DIGISEL CASE 1
MP9 8510018470 3009 DIGISEL COVER 1
MP14 8810007231 SET SCREWH M3×8 ZC3 7
MP15 8810007231 SET SCREWH M3×8 ZC3 6
REF PART
DESCRIPTION QTY.
NO. NO.
[FRONT UNIT]
REF PART
DESCRIPTION QTY.
NO. NO.
[PA UNIT]
J101* 6510028210 SJ050010 (TMP-J01X-V6) 1
J591* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J701* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J721* 6510022311 B5B-PH-SM4-TB (LF) (SN) 1
J941 6510028210 SJ050010 (TMP-J01X-V6) 1
F431* 5220000400 FHA010-01F 1
F432 5210000940 1205 1
W1* 8900017860 OPC-1857 1
MP301 8930075440 3015 RUG SPRING 1
MP302 8930075440 3015 RUG SPRING 1
REF PART
DESCRIPTION QTY.
NO. NO.
[TUNER UNIT]
W2001* 8970024721 1.5DCOAXIAL140MM-1 C31/C31 1
J1001* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1002* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1003* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1801* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J2001* 6510028210 SJ050010 (TMP-J01X-V6) 1
J2002* 6510028210 SJ050010 (TMP-J01X-V6) 1
J2003* 6510028210 SJ050010 (TMP-J01X-V6) 1
MP1301* 8510013390 2355 MIX CASE 1
MP2001*
8930094090 3768 ANT SPRING 1
MP2002*
8930094090 3768 ANT SPRING 1
DS1 5030004250 LVCG9ZA04YS 1
W11** 8600037640 SX3864 P11*P12FR (3864-4) 1
W21** 8900009231 OPC-908A (P1N10L60) 1
W22** 8900009231 OPC-908A (P1N10L60) 1
W23** 8900009231 OPC-908A (P1N10L60) 1
W24** 8900009231 OPC-908A (P1N10L60) 1
EP1 0880002780 EX-3210 #01 1
EP2 6910022560 SNAP PLATE 1
EP3 6910022560 SNAP PLATE 1
EP10 0880004510 EX-3956 #11 1
MP1 8210032661 3864 FRONT PANEL -1 1
MP20 8610016280 KNOB K-311 ASSEMBLY 1
MP21 8610016300 KNOB K-312 ASSEMBLY 1
MP22 8610016310 KNOB K-313 ASSEMBLY 2
MP23 8610016020 KNOB K-314 1
MP24 8610016030 KNOB K-315 1
MP25 8610016040 KNOB K-316 1
MP26 8610016050 KNOB K-317 1
MP27 8610016060 KNOB K-318 1
MP28 8610016070 KNOB K-319 1
MP29 8610016080 KNOB K-320 1
MP30 8610016090 KNOB K-321 1
MP40 8610016321 KNOB N-447 ASSEMBLY-1 1
MP41 8110011190 KNOB N-447 COVER (TOP) 1
MP42 8930095990 3864 BRAKE BUTTON 1
MP45 8930098800 HIMELON SHEET (EC) 3
MP50 8610016100 KNOB N-441 3
MP51 8610016180 KNOB N-442 3
MP52 8610016190 KNOB N-443 1
MP53 8610016200 KNOB N-444 1
MP54 8610016210 KNOB N-445 1
MP55 8610016350 KNOB N-446 ASSEMBLY 1
MP60 8010024090 3864 SUB CHASSIS ASSEMBLY 1
MP62 8930096770 3864 LCD SPONGE 1
MP63 8930080340 DOUBLE SIDE TAPE (BH) 1
MP70 8310064660 2590 NAME PLATE (A) (SILVER) 1
MP80 8930077360 3073 BRAKE PAD 2
MP81 8930094550 3765 BRAKE SHEET 1
MP83 8810003560 M4×6 SUS 1
MP100 8810008631 PHBT M3×6 NI-ZC3 2
MP101 8810008761 PHBT M2×8 NI-ZC3 19
