Icom IC-7610

6-3
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head NI: Nickel ZU: Zinc SUS: Stainless
REF PART
DESCRIPTION QTY.
NO. NO.
[MIC UNIT]
REF PART
DESCRIPTION QTY.
NO. NO.
[DISPLAY UNIT]
J101* 6510023261 B6B-PH-SM4-TB (LF) (SN) 1
J201* 6510031070 AYF534035 1
J203* 6510022891 B13B-ZR-SM4-TF (LF) (SN) 1
J501* 6510019971 52808-1071 1
J502* 6510018921 B8B-PH-SM4-TB (LF) (SN) 1
J503* 6510019421 B8B-ZR-SM4-TF (LF) (SN) 1
J504* 6510019971 52808-1071 1
J702* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J771* 6510019971 52808 -1071 1
J801* 6510019971 52808-1071 1
J821* 6510015541 B4B-ZR-SM4-TF (LF) (SN) 1
J902* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
S501* 2260002740 LS8J2M-T 1
S502* 2260002740 LS8J2M-T 1
S503* 2260002740 LS8J2M-T 1
S504* 2260002740 LS8J2M-T 1
S505* 2260002740 LS8J2M-T 1
S506* 2260002740 LS8J2M-T 1
S601* 2260002740 LS8J2M-T 1
S602* 2260002740 LS8J2M-T 1
S603* 2260002740 LS8J2M-T 1
S604* 2260002740 LS8J2M-T 1
S605* 2260002740 LS8J2M-T 1
S607* 2260002740 LS8J2M-T 1
S608* 2260002740 LS8J2M-T 1
S609* 2260002740 LS8J2M-T 1
S610* 2260002740 LS8J2M-T 1
S611* 2260002740 LS8J2M-T 1
S701* 2260002740 LS8J2M-T 1
S702* 2260002740 LS8J2M-T 1
S703* 2260002740 LS8J2M-T 1
S704* 2260002740 LS8J2M-T 1
S705* 2260002740 LS8J2M-T 1
S706* 2260002740 LS8J2M-T 1
S707* 2260002740 LS8J2M-T 1
S708* 2260002740 LS8J2M-T 1
S709* 2260002740 LS8J2M-T 1
S710* 2260002740 LS8J2M-T 1
S711* 2260002740 LS8J2M-T 1
S712* 2260002740 LS8J2M-T 1
S713* 2260002740 LS8J2M-T 1
S714* 2260002740 LS8J2M-T 1
S715* 2260002740 LS8J2M-T 1
S716* 2260002740 LS8J2M-T 1
S841* 2260002740 LS8J2M-T 1
S842* 2260002740 LS8J2M-T 1
S843* 2260002740 LS8J2M-T 1
S844* 2260002740 LS8J2M-T 1
S845* 2260002740 LS8J2M-T 1
MP101 8930098680 INSULATION SHEET (OO) 1
J1 6510000191 FM214-8SS (P)-1 1
J2* 6510019421 B8B-ZR-SM4-TF (LF) (SN) 1
REF PART
DESCRIPTION QTY.
NO. NO.
[USB UNIT]
J107 6510026080 XM7A-0441 1
J108 6510026080 XM7A-0441 1
J109* 6510021261 B9B-ZR-SM4-TF (LF) (SN) 1
REF PART
DESCRIPTION QTY.
NO. NO.
[SD UNIT]
J1* 6510024531 14FH-SM1-TB (LF) (SN) 1
J2* 6510028980 SCDABA0500 1
REF PART
DESCRIPTION QTY.
NO. NO.
[JACK UNIT]
J1* 6510020711 52793-1070 1
J102 6510023900 LGR4619-7000 1
J103 6510027890 01J0370-00 1
REF PART
DESCRIPTION QTY.
NO. NO.
[VR UNIT]
J1* 6510020711 52793-1070 1
J2* 6510027990 SM02B-BHSS-1-TB (LF) (SN) 1
REF PART
DESCRIPTION QTY.
NO. NO.
[MULTI UNIT]
J2* 6510020711 52793-1070 1
S1 2250001030 RE1107CM1-V03-4673 1
REF PART
DESCRIPTION QTY.
NO. NO.
[PBT UNIT]
J1* 6510020711 52793-1070 1
S1 2250000960 TP90D96AE20-30.5F-3765 1
REF PART
DESCRIPTION QTY.
NO. NO.
[BPF-A UNIT]
J1001* 6510030150 40RF-JMCS-G-1B-TF (N) (LF) (SN) 1
J1002* 6510030220 50RF-JMCS-G-1B-TF (N) (LF) (SN) 1
MP1001* 8930059930 SPONGE (HG) 1
MP1002* 8930059930 SPONGE (HG) 1
REF PART
DESCRIPTION QTY.
NO. NO.
[BPF-B UNIT]
J1001* 6510030150 40RF-JMCS-G-1B-TF (N) (LF) (SN) 1
J1002* 6510030220 50RF-JMCS-G-1B-TF (N) (LF) (SN) 1
MP1001* 8930059930 SPONGE (HG) 1
MP1002* 8930059930 SPONGE (HG) 1
