Icom IC-A14 Service Manual

5 - 5
M.=Mou
n
[PA UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C717 4030017460 S.CER ECJ0EB1E102K T 20.3/21.9
C764 4030016930 S.CER ECJ0EB1A104K T 18.8/14
C765 4030017460 S.CER ECJ0EB1E102K B 11.6/15.5
C766 4030017460 S.CER ECJ0EB1E102K B 19.4/19.8
C770 4030017460 S.CER ECJ0EB1E102K B 5.9/14.2
C790 4030017460 S.CER ECJ0EB1E102K T 5.3/14.5
C791 4030007110 S.CER C1608 CH 1H 680J-T B 25.2/12.9
C792 4030017640 S.CER ECJ0EC1H150J T 25.3/15.6
C793 4030017420 S.CER ECJ0EC1H470J T 17/13.7
C794 4030017420 S.CER ECJ0EC1H470J T 11.5/14.6
C795 4030017420 S.CER ECJ0EC1H470J B 12.5/15.5
C796 4030017420 S.CER ECJ0EC1H470J B 15.6/17.2
J1 6910017680 CNR IMSA-9230B-1-04Z140-PT1
J2 6910017680 CNR IMSA-9230B-1-04Z140-PT1
J3 6910017680 CNR IMSA-9230B-1-04Z140-PT1
[ANT UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
L1 6200012910 S.COL 0.35-1.6-8TL 45.5N T 3.6/12.1
L45 6200013110 S.COL 0.35-1.6-9TL 52.0N T 3.5/8.3
R338 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 3.8/14
C210 4030007050 S.CER C1608 CH 1H 220J-T T 7.5/8.3
C211 4030006980 S.CER C1608 CH 1H 070D-T T 5.6/7.2
C212 4030017350 S.CER ECJ0EC1H020B T 5.5/9.7
[DC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C125 4030017460 S.CER ECJ0EB1E102K T 4.6/6.1
C126 4030006900 S.CER C1608 JB 1H 103K-T T 7.4/8.2
J1 6910015881 CNR 9230B-1-02Z141-PT1
EP17 6910014640 S.BEA MPZ2012S221A-T T 7.1/5.8
EP18 6910014640 S.BEA MPZ2012S221A-T T 5.8/8.2
