Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO.
DESCRIPTION M
.
H/V
LOCATION
5-6
[MAIN UNIT]
C391 4030023010 S.CER 0402B104K160CT B 13.6/33.4
C392 4030022810 S.CER 0402N330J500CT B 14.3/31.5
C393 4030022550 S.CER 0402N4R0B500CT B 15.5/31.1
C395 4030022570 S.CER 0402N6R0C500CT B 14.3/30.6
C396 4030023090 S.CER 0402B102K500CT T 39.6/11.2
C397 4030023030 S.CER 0402B103K250CT B 40.5/4.5
C398 4030023170 S.CER 0402B332K500CT T 26.8/37.6
C399 4030022850 S.CER 0402N391J500CT T 25.8/37.6
C400 4030023230 S.CER 0402B562K500CT T 26.6/34.3
C401 4030022690 S.CER 0402N151J500CT T 19.0/36.7
C402 4030023080 S.CER 0402B822K250CT T 22.1/38.5
C404 4550007550 S.TAN F931V334MAABMA T 37.3/5.4
C409 4030023010 S.CER 0402B104K160CT T 47.7/4.6
C410 4030022260 S.CER GRM033R60J105MEA2D B 39.7/14.3
C411 4030022260 S.CER GRM033R60J105MEA2D B 41.0/14.3
C412 4030023010 S.CER 0402B104K160CT B 34.1/12.5
C413 4030023010 S.CER 0402B104K160CT B 37.7/14.4
C415 4030023010 S.CER 0402B104K160CT T 39.1/18.6
C517 4030023010 S.CER 0402B104K160CT T 7.2/21.9
C520 4030022160 S.CER GRM033B31A104KE84D T 14.8/9.4
C522 4030023090 S.CER 0402B102K500CT B 11.6/23.6
C524 4030022260 S.CER GRM033R60J105MEA2D T 6.2/11.2
C525 4030023010 S.CER 0402B104K160CT B 32.3/10.2
C526 4030025420 S.CER GRM033R61A105ME15D T 10.1/12.2
C552 4030022260 S.CER GRM033R60J105MEA2D B 38.3/18.4
C556 4030023090 S.CER 0402B102K500CT T 88.7/29.3
C557 4030022260 S.CER GRM033R60J105MEA2D T 36.6/24.5
C558 4030023010 S.CER 0402B104K160CT T 81.6/13.7
C683 4030023010 S.CER 0402B104K160CT T 19.1/32.3
C684 4030022260 S.CER GRM033R60J105MEA2D T 51.9/14.2
C685 4030023010 S.CER 0402B104K160CT T 57.1/13.6
C686 4030022260 S.CER GRM033R60J105MEA2D B 7.7/18.4
C687 4030022160 S.CER GRM033B31A104KE84D B 8.4/18.4
C688 4030022160 S.CER GRM033B31A104KE84D B 24.7/24.3
C689 4030022260 S.CER GRM033R60J105MEA2D B 24.7/23.6
C690 4030025350 S.CER GRM0332C1H120JA01D B 7.4/14.5
C692 4030025350 S.CER GRM0332C1H120JA01D B 8.5/12.1
C694 4030022160 S.CER GRM033B31A104KE84D T 3.2/7.9
C695 4030023000 S.CER 0402B683K100CT T 1.5/10.2
C697 4030022140 S.CER GRM033B31H102KA12D B 13.1/25.7
C698 4030022140 S.CER GRM033B31H102KA12D B 13.2/24.9
C699 4030022140 S.CER GRM033B31H102KA12D B 13.2/24.3
C700 4030022140 S.CER GRM033B31H102KA12D B 7.4/17.5
C701 4030022140 S.CER GRM033B31H102KA12D B 7.4/16.8
C702 4030022140 S.CER GRM033B31H102KA12D B 7.4/16.2
C703 4030022140 S.CER GRM033B31H102KA12D B 7.6/15.5
C704 4030022140 S.CER GRM033B31H102KA12D B 13.2/23.6
C705 4030022260 S.CER GRM033R60J105MEA2D B 11.2/6.2
C706 4030022160 S.CER GRM033B31A104KE84D B 11.2/7.0
C707 4030022160 S.CER GRM033B31A104KE84D B 27.4/9.2
C708 4030022260 S.CER GRM033R60J105MEA2D B 28.1/9.2
C710 4030022260 S.CER GRM033R60J105MEA2D T 84.2/31.7
C711 4030022260 S.CER GRM033R60J105MEA2D T 94.7/15.4
C712 4030022260 S.CER GRM033R60J105MEA2D T 5.9/12.6
C713 4030023010 S.CER 0402B104K160CT T 34.1/23.4
C714 4030022630 S.CER 0402N100C500CT B 67.4/23.7
C715 4030022630 S.CER 0402N100C500CT B 62.6/38.0
C716 4030023090 S.CER 0402B102K500CT T 77.9/27.8
C717 4030022260 S.CER GRM033R60J105MEA2D T 97.2/17.1
C718 4030022260 S.CER GRM033R60J105MEA2D T 95.5/21.0
C719 4030022260 S.CER GRM033R60J105MEA2D T 78.5/28.9
C720 4030022260 S.CER GRM033R60J105MEA2D T 79.1/28.7
C721 4030022260 S.CER GRM033R60J105MEA2D T 3.2/7.3
J2 6450002530 CON HSJ4456-010320
J3 6450000131 CON HSJ1102-018540
J500 6510032890 S.CON IMSA-9681S-22Y901 T 9.5/32.6
DS503 5030004520 LCD L8-1229TRW
DS504 5040003800 S.LED KA-2810ACGSK T 54.3/39.9
DS505 5040003800 S.LED KA-2810ACGSK T 54.3/5.5
MC1 7700003280 S.MIC SPU0410HR5H-PB-7 T 67.8/42.2
S500 2260003490 S.SWI TAFG-12W-QR T 85.4/43.2
S502 2260003490 S.SWI TAFG-12W-QR T 61.7/42.9
S503 2260003490 S.SWI TAFG-12W-QR T 52.2/42.9
S504 2230001060 S.SWI EVQ-PUL 02K T 101.4/13.7
EP1 6910014730 S.BEA MPZ2012S331A-T T 75.7/21.7
EP2 6910014730 S.BEA MPZ2012S331A-T T 76.2/23.7
EP3 6910014730 S.BEA MPZ2012S331A-T B 75.0/8.0
EP4 6910014730 S.BEA MPZ2012S331A-T B 67.0/13.8
EP6 6910020610 S.BEA BLM15BD102SN1D B 66.1/8.1
EP7 6910020610 S.BEA BLM15BD102SN1D B 41.2/24.6
EP8 6910020610 S.BEA BLM15BD102SN1D B 36.2/27.0
EP9 6910014730 S.BEA MPZ2012S331A-T B 81.2/6.9
EP10 6910014730 S.BEA MPZ2012S331A-T B 87.2/7.8
EP11 6910014730 S.BEA MPZ2012S331A-T B 83.5/7.7
EP12 6910020610 S.BEA BLM15BD102SN1D T 42.8/21.0
EP13 6910020610 S.BEA BLM15BD102SN1D B 39.3/19.0
EP14 6910014640 S.BEA MPZ2012S221A-T T 77.5/32.5
EP15 6910014640 S.BEA MPZ2012S221A-T T 73.2/29.7
EP16 6910014640 S.BEA MPZ2012S221A-T B 80.8/19.6
EP18 6910020610 S.BEA BLM15BD102SN1D T 11.7/10.6
EP21 6910014640 S.BEA MPZ2012S221A-T T 75.6/28.9
