Icom IC-A25Ce Service Manual

Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
5-10a
R77 7030016040 S.RES RMC1/16S-224JTH (220 k) [#13] B 24.8/25.0
7030016040 S.RES RMC1/16S-224JTH (220 k) [#14]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#16]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#17]
R78 7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#13] B 26.5/25.5
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#14]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#16]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#17]
R79 7030016120 S.RES RMC1/16S-682JTH (6.8 k) [#13] B 24.8/13.4
7030016120 S.RES RMC1/16S-682JTH (6.8 k) [#14]
7030016120 S.RES RMC1/16S-682JTH (6.8 k) [#16]
7030016120 S.RES RMC1/16S-682JTH (6.8 k) [#17]
R80 7030016030 S.RES RMC1/16S-154JTH (150 k) [#13] B 26.0/15.4
7030016030 S.RES RMC1/16S-154JTH (150 k) [#14]
7030016030 S.RES RMC1/16S-154JTH (150 k) [#16]
7030016030 S.RES RMC1/16S-154JTH (150 k) [#17]
R81 7030016290 S.RES RMC1/16S-222JTH (2.2 k) [#13] B 23.9/15.0
7030016290 S.RES RMC1/16S-222JTH (2.2 k) [#14]
7030016290 S.RES RMC1/16S-222JTH (2.2 k) [#16]
7030016290 S.RES RMC1/16S-222JTH (2.2 k) [#17]
R82 7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#13] B 26.4/13.3
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#14]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#16]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#17]
R83 7030016040 S.RES RMC1/16S-224JTH (220 k) [#13] B 22.4/15.3
7030016040 S.RES RMC1/16S-224JTH (220 k) [#14]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#16]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#17]
R84 7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#13] B 16.6/18.5
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#14]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#16]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#17]
R85 7030016360 S.RES RMC1/16S-123JTH (12 k) [#13] B 14.4/21.3
7030016360 S.RES RMC1/16S-123JTH (12 k) [#14]
7030016360 S.RES RMC1/16S-123JTH (12 k) [#16]
7030016360 S.RES RMC1/16S-123JTH (12 k) [#17]
R86 7030016560 S.RES RMC1/16SJPTH [#13] B 15.3/21.3
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R88 7030016000 S.RES RMC1/16S-823JTH (82 k) [#13] B 18.2/23.5
7030016000 S.RES RMC1/16S-823JTH (82 k) [#14]
7030016000 S.RES RMC1/16S-823JTH (82 k) [#16]
7030016000 S.RES RMC1/16S-823JTH (82 k) [#17]
R91 7030016100 S.RES RMC1/16S-334JTH (330 k) [#13] B 23.0/10.4
7030016100 S.RES RMC1/16S-334JTH (330 k) [#14]
7030016100 S.RES RMC1/16S-334JTH (330 k) [#16]
7030016100 S.RES RMC1/16S-334JTH (330 k) [#17]
R93 7030016070 S.RES RMC1/16S-474JTH (470 k) [#13] B 21.5/14.4
7030016070 S.RES RMC1/16S-474JTH (470 k) [#14]
7030016070 S.RES RMC1/16S-474JTH (470 k) [#16]
7030016070 S.RES RMC1/16S-474JTH (470 k) [#17]
R94 7030016450 S.RES RMC1/16S-824JTH (820 k) [#13] B 23.0/13.7
7030016450 S.RES RMC1/16S-824JTH (820 k) [#14]
7030016450 S.RES RMC1/16S-824JTH (820 k) [#16]
7030016450 S.RES RMC1/16S-824JTH (820 k) [#17]
R95 7030016090 S.RES RMC1/16S-223JTH (22 k) [#13] B 19.2/13.0
7030016090 S.RES RMC1/16S-223JTH (22 k) [#14]
7030016090 S.RES RMC1/16S-223JTH (22 k) [#16]
7030016090 S.RES RMC1/16S-223JTH (22 k) [#17]
R112 7030016320 S.RES RMC1/16S-225JTH (2.2 M) [#13] B 16.7/11.0
7030016320 S.RES RMC1/16S-225JTH (2.2 M) [#14]
7030016320 S.RES RMC1/16S-225JTH (2.2 M) [#16]
7030016320 S.RES RMC1/16S-225JTH (2.2 M) [#17]
R145 7030016060 S.RES RMC1/16S-105JTH (1 M) T 2.2/13.8
R146 7030016060 S.RES RMC1/16S-105JTH (1 M) T 2.7/14.8
R147 7030016060 S.RES RMC1/16S-105JTH (1 M) T 5.6/13.8
R148 7030016060 S.RES RMC1/16S-105JTH (1 M) T 4.1/9.3
R151 7510001661 S.THR NTCG16 4LH 473JT T 34.8/24.7
R152 7030008270 S.RES RR0510P-104-D (100 k) T 36.8/25.5
R558 7030016360 S.RES RMC1/16S-123JTH (12 k) [#13] B 21.5/9.8
7030016360 S.RES RMC1/16S-123JTH (12 k) [#14]
7030016360 S.RES RMC1/16S-123JTH (12 k) [#16]
7030016360 S.RES RMC1/16S-123JTH (12 k) [#17]
R595 7030015520 S.RES RMC1/16JPTP B 28.0/32.2
R856 7030015900 S.RES RMC1/16S-470JTH (47) [#13] B 19.2/88.3
7030015900 S.RES RMC1/16S-470JTH (47) [#14]
7030015900 S.RES RMC1/16S-470JTH (47) [#16]
7030015900 S.RES RMC1/16S-470JTH (47) [#17]
R857 7030016560 S.RES RMC1/16SJPTH [#13] B 18.8/85.4
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R858 7030016560 S.RES RMC1/16SJPTH [#13] B 21.5/79.2
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560
S.RES RMC1/16SJPTH [#17]
R859 7030016560 S.RES RMC1/16SJPTH [#13] B 28.7/86.5
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R860 7030016020 S.RES RMC1/16S-104JTH (100 k) [#13] B 28.7/87.4
7030016020 S.RES RMC1/16S-104JTH (100 k) [#14]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#16]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#17]
R861 7030016020 S.RES RMC1/16S-104JTH (100 k) [#13] B 29.7/97.1
7030016020 S.RES RMC1/16S-104JTH (100 k) [#14]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#16]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#17]
R862 7030016560 S.RES RMC1/16SJPTH [#13] B 28.9/98.0
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R863 7030016560 S.RES RMC1/16SJPTH [#13] T 22.8/16.1
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R864 7030016110 S.RES RMC1/16S-473JTH (47 k) [#13] B 40.1/16.4
7030016110 S.RES RMC1/16S-473JTH (47 k) [#14]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#16]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#17]
R865 7030016110 S.RES RMC1/16S-473JTH (47 k) [#13] B 38.5/15.3
7030016110 S.RES RMC1/16S-473JTH (47 k) [#14]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#16]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#17]
R866 7030016020 S.RES RMC1/16S-104JTH (100 k) [#13] T 21.9/17.9
7030016020 S.RES RMC1/16S-104JTH (100 k) [#14]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#16]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#17]
R867 7030016020 S.RES RMC1/16S-104JTH (100 k) [#13] B 40.1/12.9
7030016020 S.RES RMC1/16S-104JTH (100 k) [#14]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#16]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#17]
R868 7030016110 S.RES RMC1/16S-473JTH (47 k) [#13] B 40.1/14.1
7030016110 S.RES RMC1/16S-473JTH (47 k) [#14]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#16]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#17]
R869 7030016110 S.RES RMC1/16S-473JTH (47 k) [#13] B 40.1/15.3
7030016110 S.RES RMC1/16S-473JTH (47 k) [#14]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#16]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#17]
R871 7030015970 S.RES RMC1/16S-103JTH (10 k) [#13] B 36.3/11.8
7030015970 S.RES RMC1/16S-103JTH (10 k) [#14]
7030015970 S.RES RMC1/16S-103JTH (10 k) [#16]
7030015970 S.RES RMC1/16S-103JTH (10 k) [#17]
R873 7030016050 S.RES RMC1/16S-102JTH (1 k) [#13] B 38.7/8.4
7030016050 S.RES RMC1/16S-102JTH (1 k) [#14]
7030016050 S.RES RMC1/16S-102JTH (1 k) [#16]
7030016050 S.RES RMC1/16S-102JTH (1 k) [#17]
R874 7030016190 S.RES RMC1/16S-273JTH (27 k) [#13] B 39.0/2.4
7030016190 S.RES RMC1/16S-273JTH (27 k) [#14]
7030016190 S.RES RMC1/16S-273JTH (27 k) [#16]
7030016190 S.RES RMC1/16S-273JTH (27 k) [#17]
R875 7030016190 S.RES RMC1/16S-273JTH (27 k) [#13] B 40.8/4.3
7030016190 S.RES RMC1/16S-273JTH (27 k) [#14]
7030016190 S.RES RMC1/16S-273JTH (27 k) [#16]
7030016190 S.RES RMC1/16S-273JTH (27 k) [#17]
R876 7030016160 S.RES RMC1/16S-820JTH (82) T 33.0/35.2
R878 7030015920 S.RES RMC1/16S-221JTH (220) T 13.2/14.6
R879 7030016020 S.RES RMC1/16S-104JTH (100 k) [#13] B 41.3/5.5
7030016020 S.RES RMC1/16S-104JTH (100 k) [#14]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#16]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#17]
R881 7030016110 S.RES RMC1/16S-473JTH (47 k) B 27.9/18.5
R882 7030015970 S.RES RMC1/16S-103JTH (10 k) B 29.6/16.9
R883 7030016380 S.RES RMC1/16S-183JTH (18 k) B 30.9/17.3
R884 7030016360 S.RES RMC1/16S-123JTH (12 k) B 30.9/14.1
R885 7030015970 S.RES RMC1/16S-103JTH (10 k) B 39.2/28.6
R886 7030016380 S.RES RMC1/16S-183JTH (18 k) B 38.0/28.1
R887 7030016560 S.RES RMC1/16SJPTH B 38.0/30.2
R888 7030015970 S.RES RMC1/16S-103JTH (10 k) B 42.8/31.9
R901 7030014460 S.RES MCR006YZPJ 101 (100) B 30.3/43.5
R902 7030014460 S.RES MCR006YZPJ 101 (100) B 23.5/43.3
R903 7030014460 S.RES MCR006YZPJ 101 (100) B 30.2/61.4
R906 7030014460 S.RES MCR006YZPJ 101 (100) B 23.5/62.3
R907 7030014460 S.RES MCR006YZPJ 101 (100) B 39.2/50.1
R908 7030016060 S.RES RMC1/16S-105JTH (1 M) B 37.1/52.9
R909 7030016150 S.RES RMC1/16S-100JTH (10) B 35.8/53.0
R910 7030016360 S.RES RMC1/16S-123JTH (12 k) B 39.3/57.6
R911 7030016090 S.RES RMC1/16S-223JTH (22 k) B 39.3/56.7
R912 7030016360 S.RES RMC1/16S-123JTH (12 k) B 42.0/58.4
R913 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 26.0/67.7
R914 7030016020 S.RES RMC1/16S-104JTH (100 k) B 25.0/68.2
R917 7030016020 S.RES RMC1/16S-104JTH (100 k) T 24.1/21.2
R920 7030016020 S.RES RMC1/16S-104JTH (100 k) T 23.7/20.0
R925 7030015970 S.RES RMC1/16S-103JTH (10 k) B 44.4/52.9
R926 7030016560 S.RES RMC1/16SJPTH [#13] B 9.9/16.2
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R927 7030016560 S.RES RMC1/16SJPTH [#13] B 20.7/15.3
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R928 7030016560 S.RES RMC1/16SJPTH [#13] B 21.3/26.2
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R929 7030014460 S.RES MCR006YZPJ 101 (100) [#13] B 24.6/50.9
7030014460 S.RES MCR006YZPJ 101 (100) [#14]
7030014460 S.RES MCR006YZPJ 101 (100) [#16]
7030014460 S.RES MCR006YZPJ 101 (100) [#17]
R930 7030014460 S.RES MCR006YZPJ 101 (100) [#13] B 24.0/51.9
7030014460 S.RES MCR006YZPJ 101 (100) [#14]
7030014460 S.RES MCR006YZPJ 101 (100) [#16]
7030014460 S.RES MCR006YZPJ 101 (100) [#17]
R931 7030016020 S.RES RMC1/16S-104JTH (100 k) B 23.8/49.3
R932 7030016020 S.RES RMC1/16S-104JTH (100 k) B 23.4/50.5
R933 7030015970 S.RES RMC1/16S-103JTH (10 k) B 22.1/69.6
The underlined parts have been updated from the previous version of the addendum, or the original page.
[LOGIC-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
[LOGIC-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
