Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
5-15a
L91 6200003550 S.COI MLF1608A 4R7K-T T 15.4/40.9
L92 6200011050 S.COI C2012C-R12G-A T 9.2/38.4
L93 6200014370 S.COI MLF1005L 2R2K-T B 26.3/91.2
L94 6200014370 S.COI MLF1005L 2R2K-T B 25.3/81.3
L95 6200014370 S.COI MLF1005L 2R2K-T B 31.0/79.2
L96 6200014370 S.COI MLF1005L 2R2K-T B 32.4/91.3
L97 6200011650 S.COI LQW18AN68NG00D B 25.3/95.7
L99 6200014260 S.COI LQM2MPN2R2NG0L B 27.5/7.7
L100 6200014260 S.COI LQM2MPN2R2NG0L B 37.0/7.4
R2 7030015780 S.RES RMC1/10-331JTP (330) T 12.3/107.0
R3 7030016090 S.RES RMC1/16S-223JTH (22 k) T 9.5/67.1
R4 7030015910 S.RES RMC1/16S-101JTH (100) T 9.9/66.2
R5 7030016020 S.RES RMC1/16S-104JTH (100 k) T 6.8/71.8
R7 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 14.6/104.2
R8 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 13.5/97.2
R9 7030015780 S.RES RMC1/10-331JTP (330) T 12.2/105.2
R10 7030015930 S.RES RMC1/16S-471JTH (470) T 6.0/74.2
R11 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 6.8/70.9
R12 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 9.0/70.9
R13 7030016090 S.RES RMC1/16S-223JTH (22 k) T 8.0/72.2
R14 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 6.5/81.4
R15 7030015910 S.RES RMC1/16S-101JTH (100) T 9.0/81.3
R16 7030015980 S.RES RMC1/16S-333JTH (33 k) T 7.8/82.1
R17 7030016110 S.RES RMC1/16S-473JTH (47 k) T 5.9/77.2
R18 7030015920 S.RES RMC1/16S-221JTH (220) T 8.7/74.6
R19 7510001461 S.THE NTCG16 3NH 471JT T 6.9/75.7
R20 7030015680 S.RES RMC1/10-150JTP (15) B 16.1/64.0
R21 7030016050 S.RES RMC1/16S-102JTH (1 k) B 7.7/63.9
R22 7030016050 S.RES RMC1/16S-102JTH (1 k) B 13.7/63.0
R23 7030016150 S.RES RMC1/16S-100JTH (10) B 7.0/65.3
R24 7030016210 S.RES RMC1/16S-121JTH (120) B 9.6/60.5
R25 7030015900 S.RES RMC1/16S-470JTH (47) B 11.0/59.4
R26 7030016210 S.RES RMC1/16S-121JTH (120) B 9.6/58.0
R27 7030015920 S.RES RMC1/16S-221JTH (220) T 16.2/72.8
R28 7030016080 S.RES RMC1/16S-822JTH (8.2 k) T 11.8/57.9
R29 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 10.1/58.8
R39 7030015970 S.RES RMC1/16S-103JTH (10 k) B 11.9/57.6
R40 7030016330 S.RES RMC1/16S-153JTH (15 k) T 10.1/57.9
R41 7030015930 S.RES RMC1/16S-471JTH (470) B 13.9/105.3
R43 7030016040 S.RES RMC1/16S-224JTH (220 k) B 19.9/100.5
R44 7030016000 S.RES RMC1/16S-823JTH (82 k) B 32.7/106.7
R45 7030016110 S.RES RMC1/16S-473JTH (47 k) B 31.8/106.7
R47 7030016500 S.RES RMC1/16S-562JTH (5.6 k) B 13.9/107.3
R48 7030016540 S.RES RMC1/16SK334FTH (330 k) B 36.2/106.7
R49 7030015900 S.RES RMC1/16S-470JTH (47) B 33.9/107.1
R51 7030016370 S.RES RMC1/16S-271JTH (270) B 30.5/103.9
R52 7030016050 S.RES RMC1/16S-102JTH (1 k) B 33.8/102.4
R53 7030015910 S.RES RMC1/16S-101JTH (100) B 10.0/107.4
R54 7030016040 S.RES RMC1/16S-224JTH (220 k) B 28.7/101.4
R58 7030016040 S.RES RMC1/16S-224JTH (220 k) B 29.6/98.5
R59 7030016030 S.RES RMC1/16S-154JTH (150 k) B 33.6/96.9
R60 7030015990 S.RES RMC1/16S-683JTH (68 k) B 33.6/98.0
R62 7030016390 S.RES RMC1/16S-184JTH (180 k) B 25.3/93.6
R63 7030015990 S.RES RMC1/16S-683JTH (68 k) B 23.2/93.8
R64 7030015910 S.RES RMC1/16S-101JTH (100) B 30.9/92.8
R65 7030016180 S.RES RMC1/16S-680JTH (68) B 26.4/94.7
R66 7030016050 S.RES RMC1/16S-102JTH (1 k) B 33.1/95.0
R67 7030016560 S.RES RMC1/16SJPTH B 33.9/106.2
R68 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 25.4/79.2
R69 7030016050 S.RES RMC1/16S-102JTH (1 k) B 26.0/75.2
R70 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 25.2/80.1
R71 7030016050 S.RES RMC1/16S-102JTH (1 k) T 40.4/67.8
R72 7030016220 S.RES RMC1/16S-563JTH (56 k) B 34.0/65.7
R73 7030015970 S.RES RMC1/16S-103JTH (10 k) B 29.9/68.1
R74 7030016150 S.RES RMC1/16S-100JTH (10) B 39.1/78.9
R75 7030016040 S.RES RMC1/16S-224JTH (220 k) B 40.6/81.2
R76 7030016020 S.RES RMC1/16S-104JTH (100 k) B 31.2/73.1
R77 7030016050 S.RES RMC1/16S-102JTH (1 k) B 34.0/68.1
R79 7030015970 S.RES RMC1/16S-103JTH (10 k) B 30.3/71.5
R80 7030016020 S.RES RMC1/16S-104JTH (100 k) B 28.2/71.8
R81 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 27.3/68.1
R82 7030016070 S.RES RMC1/16S-474JTH (470 k) B 30.8/70.2
R83 7030016090 S.RES RMC1/16S-223JTH (22 k) B 40.6/82.1
R87 7030015910 S.RES RMC1/16S-101JTH (100) T 41.7/68.3
R90 7030016040 S.RES RMC1/16S-224JTH (220 k) B 29.9/66.9
R94 7030016560 S.RES RMC1/16SJPTH B 29.9/70.2
R99 7030016110 S.RES RMC1/16S-473JTH (47 k) B 28.9/66.9
R100 7030016000 S.RES RMC1/16S-823JTH (82 k) B 27.7/66.4
R101 7030016100 S.RES RMC1/16S-334JTH (330 k) B 30.2/65.6
R102 7030016320 S.RES RMC1/16S-225JTH (2.2 M) B 30.2/63.3
R107 7030015780 S.RES RMC1/10-331JTP (330) T 37.0/106.9
R108 7030015690 S.RES RMC1/10-180JTP (18) T 33.5/106.5
R109 7030015970 S.RES RMC1/16S-103JTH (10 k) T 31.8/107.4
R111 7030015970 S.RES RMC1/16S-103JTH (10 k) B 9.6/57.1
R114 7030016370 S.RES RMC1/16S-271JTH (270) B 13.6/57.1
R115 7030016090 S.RES RMC1/16S-223JTH (22 k) B 13.0/53.7
R117 7030015920 S.RES RMC1/16S-221JTH (220) B 11.6/50.8
R118 7030016130 S.RES RMC1/16S-150JTH (15) T 10.7/50.7
R119 7030016050 S.RES RMC1/16S-102JTH (1 k) B 15.9/50.0
R120 7030016110 S.RES RMC1/16S-473JTH (47 k) B 13.1/50.2
R121 7030015910 S.RES RMC1/16S-101JTH (100) B 15.0/48.8
R122 7030016170 S.RES RMC1/16S-560JTH (56) B 26.7/41.0
R123 7030011000 S.RES RR0510P-392-D (3.9 k) T 20.9/47.3
R124 7030011000 S.RES RR0510P-392-D (3.9 k) T 8.8/46.3
R130 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 4.4/52.9
R134 7030015930 S.RES RMC1/16S-471JTH (470) B 23.6/44.2
R135 7030016480 S.RES RMC1/16S-821JTH (820) B 24.5/47.1
R140 7030016020 S.RES RMC1/16S-104JTH (100 k) B 29.7/23.2
R142 7030015640 S.RES RMC1/10JPTP T 18.5/31.3
R145 7030005820 S.RES RR0510P-103-D (10 k) B 21.0/27.9
R147 7030005950 S.RES RR0510P-123-D (12 k) B 19.8/28.3
R148 7030016050 S.RES RMC1/16S-102JTH (1 k) B 19.1/26.5
R150 7030016020 S.RES RMC1/16S-104JTH (100 k) B 21.6/23.4
R192 7030016740 S.RES RMC1/16SK474DTH (470 k) T 35.5/16.1
R193 7030016750 S.RES RMC1/16SK124DTH (120 k) T 34.7/19.6
R194 7030016740 S.RES RMC1/16SK474DTH (470 k) T 19.9/109.9
R195 7030016750 S.RES RMC1/16SK124DTH (120 k) T 17.3/109.4
R210 7030016560 S.RES RMC1/16SJPTH B 33.3/23.2
R211 7030016390 S.RES RMC1/16S-184JTH (180 k) B 28.0/58.0
R212 7030016110 S.RES RMC1/16S-473JTH (47 k) B 27.8/56.8
R213 7030016340 S.RES RMC1/16S-393JTH (39 k) B 29.6/56.6
R214 7030016450 S.RES RMC1/16S-824JTH (820 k) B 23.5/57.0
R219 7030015660 S.RES RMC1/10-2R7JTP (2.7) T 11.2/79.6
R220 7030015930 S.RES RMC1/16S-471JTH (470) B 40.8/117.2
R222 7030016040 S.RES RMC1/16S-224JTH (220 k) B 44.7/115.2
R223 7030015970 S.RES RMC1/16S-103JTH (10 k) B 42.3/113.8
R224 7030016330 S.RES RMC1/16S-153JTH (15 k) B 44.5/113.1
R225 7030015970 S.RES RMC1/16S-103JTH (10 k) B 37.7/26.3
R226 7030016090 S.RES RMC1/16S-223JTH (22 k) T 35.6/101.7
R227 7030016050 S.RES RMC1/16S-102JTH (1 k) T 39.4/44.1
R231 7030016560 S.RES RMC1/16SJPTH T 37.1/32.8
R252 7030016560 S.RES RMC1/16SJPTH B 25.5/44.4
R253 7030016490 S.RES RMC1/16S-391JTH (390) B 24.6/44.4
R254 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 10.9/44.2
R256 7030011920 S.RES RR0510P-561-D (560) T 20.9/48.6
R258 7030008340 S.RES RR0510P-182-D (1.8 k) T 17.8/46.1
R260 7030008340 S.RES RR0510P-182-D (1.8 k) T 8.7/47.2
R262 7030011920 S.RES RR0510P-561-D (560) T 14.0/44.7
R265 7030015930 S.RES RMC1/16S-471JTH (470) T 18.3/50.3
R266 7030015990 S.RES RMC1/16S-683JTH (68 k) T 17.1/49.3
R274 7030015930 S.RES RMC1/16S-471JTH (470) B 33.0/68.4
R283 7030016390 S.RES RMC1/16S-184JTH (180 k) B 29.6/57.5
R290 7030015900 S.RES RMC1/16S-470JTH (47) T 43.7/68.3
R293 7030016000 S.RES RMC1/16S-823JTH (82 k) B 35.2/106.7
R299 7030015640 S.RES RMC1/10JPTP T 17.2/79.6
R302 7030015970 S.RES RMC1/16S-103JTH (10 k) T 11.8/100.9
R303 7030015970 S.RES RMC1/16S-103JTH (10 k) T 13.2/101.6
R304 7030015970 S.RES RMC1/16S-103JTH (10 k) T 12.0/114.7
R305 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 13.6/113.0
R311 7030016040 S.RES RMC1/16S-224JTH (220 k) B 27.8/103.3
R313 7030015900 S.RES RMC1/16S-470JTH (47) B 10.3/51.4
R316 7030016090 S.RES RMC1/16S-223JTH (22 k) B 33.6/57.5
R317 7030016110 S.RES RMC1/16S-473JTH (47 k) B 31.5/56.6
R318 7030015970 S.RES RMC1/16S-103JTH (10 k) B 32.7/58.4
R319 7030016110 S.RES RMC1/16S-473JTH (47 k) B 33.6/56.6
R320 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 7.6/83.8
R321 7510001661 S.THR NTCG16 4LH 473JT T 7.4/85.2
R322 7030016190 S.RES RMC1/16S-273JTH (27 k) T 6.7/83.8
R323 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 6.4/82.5
R331 7030016050 S.RES RMC1/16S-102JTH (1 k) T 7.1/76.7
R333 7030016090 S.RES RMC1/16S-223JTH (22 k) T 8.5/77.5
R334 7030015970 S.RES RMC1/16S-103JTH (10 k) B 32.0/41.4
R338 7030016000 S.RES RMC1/16S-823JTH (82 k) T 9.2/119.6
R349 7030015640 S.RES RMC1/10JPTP B 39.6/88.5
R352 7030016270 S.RES RMC1/16S-151JTH (150) B 32.2/80.6
R353 7030016560 S.RES RMC1/16SJPTH B 31.2/90.8
R355 7030016240 S.RES RMC1/16S-684JTH (680 k) B 45.1/72.3
R357 7030016050 S.RES RMC1/16S-102JTH (1 k) B 45.1/78.7
R359 7030016050 S.RES RMC1/16S-102JTH (1 k) B 21.5/39.7
R361 7030016090 S.RES RMC1/16S-223JTH (22 k) B 27.0/82.6
R363 7030016090 S.RES RMC1/16S-223JTH (22 k) B 28.8/93.4
R366 7030015910 S.RES RMC1/16S-101JTH (100) B 23.5/81.7
R367 7030015910 S.RES RMC1/16S-101JTH (100) B 22.8/91.8
R368 7030015970 S.RES RMC1/16S-103JTH (10 k) B 14.7/54.7
R369 7030016050 S.RES RMC1/16S-102JTH (1 k) B 25.6/76.4
R370 7030016050 S.RES RMC1/16S-102JTH (1 k) B 12.2/102.0
R374 7030016330 S.RES RMC1/16S-153JTH (15 k) B 39.5/77.2
R375 7030016360 S.RES RMC1/16S-123JTH (12 k) T 27.1/87.2
R376 7030016330 S.RES RMC1/16S-153JTH (15 k) B 37.0/66.6
R377 7030016360 S.RES RMC1/16S-123JTH (12 k) T 39.4/71.7
R378 7030016270 S.RES RMC1/16S-151JTH (150) B 15.4/57.9
R379 7030016470 S.RES RMC1/16S-390JTH (39) B 14.5/57.9
R380 7030016270 S.RES RMC1/16S-151JTH (150) B 15.9/59.1
R381 7030016050 S.RES RMC1/16S-102JTH (1 k) B 29.0/73.1
R388 7030016360 S.RES RMC1/16S-123JTH (12 k) T 43.3/71.3
R389 7030016360 S.RES RMC1/16S-123JTH (12 k) T 28.5/69.3
R390 7030016050 S.RES RMC1/16S-102JTH (1 k) T 31.1/68.1
R391 7030016060 S.RES RMC1/16S-105JTH (1 M) B 33.3/36.5
R393 7030016450 S.RES RMC1/16S-824JTH (820 k) B 29.4/37.6
R394 7030016400 S.RES RMC1/16S-564JTH (560 k) B 30.8/37.0
R397 7030016560 S.RES RMC1/16SJPTH B 24.3/95.7
R398 7030016020 S.RES RMC1/16S-104JTH (100 k) B 26.5/66.3
R399 7030008270 S.RES RR0510P-104-D (100 k) B 21.1/65.4
R400 7030005840 S.RES RR0510P-473-D (47 k) B 23.7/62.4
R401 7030016560 S.RES RMC1/16SJPTH B 25.0/61.9
R405 7030015970 S.RES RMC1/16S-103JTH (10 k) B 42.8/79.0
R407 7030016110 S.RES RMC1/16S-473JTH (47 k) B 22.9/38.4
R417 7030016020 S.RES RMC1/16S-104JTH (100 k) B 40.6/39.5
R419 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 10.1/111.6
R426 7030015910 S.RES RMC1/16S-101JTH (100) B 24.1/73.7
R427 7030016060 S.RES RMC1/16S-105JTH (1 M) B 20.7/76.2
R428 7030016300 S.RES RMC1/16S-332JTH (3.3 k) B 23.2/70.8
R431 7030016560 S.RES RMC1/16SJPTH B 23.2/69.1
R432 7030016110 S.RES RMC1/16S-473JTH (47 k) T 41.2/71.7
R433 7030016110 S.RES RMC1/16S-473JTH (47 k) T 28.9/71.4
R434 7030015640 S.RES RMC1/10JPTP T 37.2/18.6
R443 7030016380 S.RES RMC1/16S-183JTH (18 k) T 35.3/102.9
R444 7030005830 S.RES RR0510P-223-D (22 k) B 26.9/42.3
The underlined parts have been updated from the previous version of the addendum, or the original page.
[MAIN-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
[MAIN-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
To Next Page
Loading...
Need help?
General
