Icom IC-A25Ce Service Manual

Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
5-18a
C405 4030023090 S.CER 0402B102K500CT B 19.4/99.2
C407 4030020450 S.CER C1005 JB 0J 475M-T B 16.3/105.4
C418 4030023090 S.CER 0402B102K500CT T 40.3/12.6
C420 4030023090 S.CER 0402B102K500CT T 37.3/104.8
C429 4030022860 S.CER 0402N470J500CT T 16.4/91.0
C430 4030021240 S.CER C1005 JB 1C 105K-T B 22.7/78.8
C431 4030023090 S.CER 0402B102K500CT T 37.2/16.9
C432 4030023090 S.CER 0402B102K500CT B 38.1/106.7
C438 4030022630 S.CER 0402N100C500CT B 32.9/41.4
C439 4030022640 S.CER 0402N101J500CT B 43.7/69.2
C440 4030023090 S.CER 0402B102K500CT B 33.8/41.4
C441 4030020000 S.CER C1005 JB 1A 105K-T B 34.8/38.9
C443 4030023090 S.CER 0402B102K500CT B 23.1/39.7
C444 4030023010 S.CER 0402B104K160CT B 35.4/46.5
C445 4030021240 S.CER C1005 JB 1C 105K-T B 34.8/44.3
C446 4030023030 S.CER 0402B103K250CT B 45.1/79.6
C451 4030023010 S.CER 0402B104K160CT B 24.4/81.3
C458 4030023010 S.CER 0402B104K160CT B 29.9/91.1
C459 4030023010 S.CER 0402B104K160CT B 31.0/80.1
C460 4030023010 S.CER 0402B104K160CT B 40.0/75.8
C461 4030023010 S.CER 0402B104K160CT T 25.3/85.9
C462 4030023010 S.CER 0402B104K160CT T 38.2/72.1
C463 4030023010 S.CER 0402B104K160CT T 26.2/72.1
C464 4030023010 S.CER 0402B104K160CT T 44.5/71.7
C466 4030023010 S.CER 0402B104K160CT T 28.9/72.3
C467 4030023010 S.CER 0402B104K160CT T 42.1/71.7
C468 4030023010 S.CER 0402B104K160CT T 26.2/86.8
C469 4030023010 S.CER 0402B104K160CT B 26.7/84.2
C470 4030023010 S.CER 0402B104K160CT B 26.6/89.5
C471 4030023010 S.CER 0402B104K160CT B 33.7/90.8
C472 4030023010 S.CER 0402B104K160CT B 33.1/80.6
C473 4030022560 S.CER 0402N5R0B500CT B 41.6/70.4
C474 4030022570 S.CER 0402N6R0C500CT B 43.9/72.8
C475 4030022880 S.CER 0402N560J500CT B 41.3/71.7
C476 4030023090 S.CER 0402B102K500CT B 26.8/80.2
C477 4030023090 S.CER 0402B102K500CT B 29.7/94.7
C478 4030023030 S.CER 0402B103K250CT B 22.0/64.9
C479 4030023030 S.CER 0402B103K250CT B 24.9/62.8
C481 4030019560 S.CER GRM21BB31C106KE15L B 9.6/109.5
C484 4030023030 S.CER 0402B103K250CT B 8.7/52.9
C485 4030023090 S.CER 0402B102K500CT T 25.7/66.2
C486 4030023090 S.CER 0402B102K500CT T 26.7/66.2
C487 4030023090 S.CER 0402B102K500CT T 27.7/66.2
C488 4030019560 S.CER GRM21BB31C106KE15L B 9.5/106.0
C489 4030020000 S.CER C1005 JB 1A 105K-T B 24.2/72.3
C490 4030023010 S.CER 0402B104K160CT B 35.7/38.9
C491 4030023090 S.CER 0402B102K500CT B 31.5/57.5
C492 4030020450 S.CER C1005 JB 0J 475M-T T 28.9/70.5
C493 4030020450 S.CER C1005 JB 0J 475M-T T 40.3/71.7
C495 4030021520 S.CER GRM31CB31H106KA12L T 19.6/82.7
C496 4030021520 S.CER GRM31CB31H106KA12L T 21.3/107.7
C508 4030023090 S.CER 0402B102K500CT T 14.4/41.4
C509 4030023090 S.CER 0402B102K500CT T 13.9/38.5
C510 4030023090 S.CER 0402B102K500CT B 26.6/45.7
C511 4030022640 S.CER 0402N101J500CT B 29.4/40.4
C512 4030024500 S.CER C1005 JB 1C 224K-T B 30.3/40.4
C513 4030019560 S.CER GRM21BB31C106KE15L B 27.6/38.7
C514 4030023010 S.CER 0402B104K160CT B 33.9/44.3
C515 4030023010 S.CER 0402B104K160CT B 32.4/48.1
C516 4030019560 S.CER GRM21BB31C106KE15L B 28.4/49.8
C517 4030023010 S.CER 0402B104K160CT B 29.9/38.8
C518 4030023090 S.CER 0402B102K500CT B 26.3/50.7
C519 4030023090 S.CER 0402B102K500CT B 28.7/47.7
C520 4030023090 S.CER 0402B102K500CT B 15.5/42.4
C521 4030023090 S.CER 0402B102K500CT B 16.4/47.7
C522 4030023090 S.CER 0402B102K500CT T 19.5/50.7
C523 4030023090 S.CER 0402B102K500CT B 21.9/38.5
C524 4030023090 S.CER 0402B102K500CT B 21.5/37.3
C525 4030023090 S.CER 0402B102K500CT B 44.1/67.8
C526 4030022630 S.CER 0402N100C500CT B 42.4/67.8
C527 4030021240 S.CER C1005 JB 1C 105K-T B 40.5/65.4
C528 4030023010 S.CER 0402B104K160CT B 39.6/65.4
C529 4030023010 S.CER 0402B104K160CT B 44.5/64.6
C530 4030021240 S.CER C1005 JB 1C 105K-T B 41.9/63.1
C531 4030023010 S.CER 0402B104K160CT T 21.0/62.0
C532 4030019560 S.CER GRM21BB31C106KE15L T 26.5/54.9
C533 4030023010 S.CER 0402B104K160CT T 24.8/54.9
C534 4030023090 S.CER 0402B102K500CT T 32.5/33.3
C535 4030023010 S.CER 0402B104K160CT T 24.8/36.0
C536 4030019560 S.CER GRM21BB31C106KE15L T 24.7/34.0
C537 4030023010 S.CER 0402B104K160CT T 30.5/33.8
C538 4520000020 S.NIO NOJC227M006RWJV T 30.3/24.2
C539 4030023090 S.CER 0402B102K500CT B 41.3/96.4
C541 4030021240 S.CER C1005 JB 1C 105K-T B 34.8/27.6
C542 4030023010 S.CER 0402B104K160CT B 34.5/23.2
C543 4030023090 S.CER 0402B102K500CT T 15.9/9.5
C544 4030023090 S.CER 0402B102K500CT T 13.0/6.6
C548 4030022930 S.CER 0402N821J500CT [#13] B 8.0/35.4
4030022930 S.CER 0402N821J500CT [#14]
4030022930 S.CER 0402N821J500CT [#23]
4030022930 S.CER 0402N821J500CT [#24]
4030022930 S.CER 0402N821J500CT [#33]
4030022930 S.CER 0402N821J500CT [#34]
C549 4030020170 S.CER C1608 CH 1H 472J-T [#13] B 5.6/31.1
4030020170 S.CER C1608 CH 1H 472J-T [#14]
4030017810 S.CER C1608 CH 1H 102J-T [#16]
4030017810 S.CER C1608 CH 1H 102J-T [#17]
4030020170 S.CER C1608 CH 1H 472J-T [#23]
4030020170 S.CER C1608 CH 1H 472J-T [#24]
4030017810 S.CER C1608 CH 1H 102J-T [#27]
4030020170 S.CER C1608 CH 1H 472J-T [#33]
4030020170 S.CER C1608 CH 1H 472J-T [#34]
4030017810 S.CER C1608 CH 1H 102J-T [#36]
C550 4030022710 S.CER 0402N181J500CT [#13] B 8.7/33.2
4030022710 S.CER 0402N181J500CT [#14]
4030022910 S.CER 0402N681J500CT [#16]
4030022910 S.CER 0402N681J500CT [#17]
4030022710 S.CER 0402N181J500CT [#23]
4030022710 S.CER 0402N181J500CT [#24]
4030022910 S.CER 0402N681J500CT [#27]
4030022710 S.CER 0402N181J500CT [#33]
4030022710 S.CER 0402N181J500CT [#34]
4030022910 S.CER 0402N681J500CT [#36]
C551 4030018620 S.CER C1608 CH 1H 222J-T B 6.0/28.1
C552 4030022690 S.CER 0402N151J500CT [#13] B 9.0/28.0
4030022690 S.CER 0402N151J500CT [#14]
4030022820 S.CER 0402N331J500CT [#16]
4030022820 S.CER 0402N331J500CT [#17]
4030022690 S.CER 0402N151J500CT [#23]
4030022690 S.CER 0402N151J500CT [#24]
4030022820 S.CER 0402N331J500CT [#27]
4030022690 S.CER 0402N151J500CT [#33]
4030022690 S.CER 0402N151J500CT [#34]
4030022820 S.CER 0402N331J500CT [#36]
C553 4030019570 S.CER C1608 CH 1H 332J-T B 5.6/19.4
C554 4030022880 S.CER 0402N560J500CT [#13] B 8.0/23.4
4030022880 S.CER 0402N560J500CT [#14]
4030022670 S.CER 0402N121J500CT [#16]
4030022670 S.CER 0402N121J500CT [#17]
4030022880 S.CER 0402N560J500CT [#23]
4030022880 S.CER 0402N560J500CT [#24]
4030022670 S.CER 0402N121J500CT [#27]
4030022880 S.CER 0402N560J500CT [#33]
4030022880 S.CER 0402N560J500CT [#34]
4030022670 S.CER 0402N121J500CT [#36]
C555 4030020160 S.CER C1608 CH 1H 103J-T [#13] B 5.5/14.7
4030020160 S.CER C1608 CH 1H 103J-T [#14]
4030022350 S.CER C1608 CH 1H 822JT [#16]
4030022350 S.CER C1608 CH 1H 822JT [#17]
4030020160 S.CER C1608 CH 1H 103J-T [#23]
4030020160 S.CER C1608 CH 1H 103J-T [#24]
4030022350 S.CER C1608 CH 1H 822JT [#27]
4030020160 S.CER
C1608 CH 1H 103J-T [#33]
4030020160 S.CER C1608 CH 1H 103J-T [#34]
4030022350 S.CER C1608 CH 1H 822JT [#36]
C556 4030022630 S.CER 0402N100C500CT [#13] B 7.6/18.5
4030022630 S.CER 0402N100C500CT [#14]
4030022630 S.CER 0402N100C500CT [#23]
4030022630 S.CER 0402N100C500CT [#24]
4030022630 S.CER 0402N100C500CT [#33]
4030022630 S.CER 0402N100C500CT [#34]
C557 4030022930 S.CER 0402N821J500CT B 11.4/35.3
C558 4030022930 S.CER 0402N821J500CT B 13.0/31.7
C559 4030022690 S.CER 0402N151J500CT B 10.5/33.2
C560 4030020170 S.CER C1608 CH 1H 472J-T B 13.7/27.4
C561 4030022870 S.CER 0402N471J500CT B 11.2/28.3
C562 4030020940 S.CER C1608 CH 1H 392JT B 14.1/22.1
C563 4030022640 S.CER 0402N101J500CT B 12.1/23.2
C564 4030020160 S.CER C1608 CH 1H 103J-T B 14.1/19.1
C565 4030022680 S.CER 0402N150J500CT B 9.3/18.3
C566 4030021240 S.CER C1005 JB 1C 105K-T T 41.5/35.4
C567 4030021240 S.CER C1005 JB 1C 105K-T T 41.9/36.8
C568 4030021240 S.CER C1005 JB 1C 105K-T T 40.9/25.9
C569 4030023010 S.CER 0402B104K160CT T 42.6/26.5
C570 4030023010 S.CER 0402B104K160CT T 39.6/26.3
C571 4030019560 S.CER GRM21BB31C106KE15L T 35.0/37.1
C572 4030019560 S.CER GRM21BB31C106KE15L T 37.6/34.9
C573 4030023090 S.CER 0402B102K500CT T 9.1/21.3
C574 4030022900 S.CER 0402N680J500CT B 27.5/10.2
C577 4030021520 S.CER GRM31CB31H106KA12L B 21.7/9.3
C579 4030021520 S.CER GRM31CB31H106KA12L B 23.8/9.3
C580 4030021520 S.CER GRM31CB31H106KA12L B 34.9/6.7
C585 4030023010 S.CER 0402B104K160CT B 25.4/9.5
C586 4030023030 S.CER 0402B103K250CT B 26.3/9.5
C587 4030022870 S.CER 0402N471J500CT B 40.4/23.7
C588 4030022860 S.CER 0402N470J500CT B 41.6/21.9
C589 4030021240 S.CER C1005 JB 1C 105K-T B 39.1/22.5
C590 4030023090 S.CER 0402B102K500CT B 35.2/87.5
C591 4030022640 S.CER 0402N101J500CT B 36.9/88.1
C592 4030022640 S.CER 0402N101J500CT B 40.1/96.7
C593 4030023090 S.CER 0402B102K500CT B 41.5/94.8
C596 4030023090 S.CER 0402B102K500CT T 11.7/10.7
C597 4030023010 S.CER 0402B104K160CT B 26.6/26.3
C598 4030021240 S.CER C1005 JB 1C 105K-T B 25.7/26.3
C599 4030023090 S.CER 0402B102K500CT T 23.4/118.8
C602 4030023090 S.CER 0402B102K500CT T 21.2/120.6
C605 4030022640 S.CER 0402N101J500CT T 28.2/123.0
C608 4030019560 S.CER GRM21BB31C106KE15L B 21.2/29.9
C610 4030023090 S.CER 0402B102K500CT T 23.0/97.1
C612 4030019560 S.CER GRM21BB31C106KE15L T 27.8/91.6
C613 4030023090 S.CER 0402B102K500CT T 22.1/100.3
C614 4030023010 S.CER 0402B104K160CT T 25.7/92.4
C615 4030023010 S.CER 0402B104K160CT T 23.9/97.1
The underlined parts have been updated from the previous version of the addendum, or the original page.
[MAIN-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
[MAIN-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
