2-2
• LOGIC/LOGIC-1 UNIT (BOTTOM VIEW)
GPS Module (IC17)*
†
Inside the shield case
J3*
CPU (IC27)
†
Under the shield plate
Clock Oscillator (X1)
†
Under the shield plate
5 V Regulator (IC40)
(for LCD Backlight)
J1
*Only for IC-A25N
