3
-2
2. R
EMOV
ING TH
E MAI
N/-1 UNIT
Unsolder 1
1 points o
n the shield p
late, and then
1
)
remove it.
MAIN/-1 UNIT
Shield plate
UNSOLDER
Solder
remover
Unsolder a p
oint at the antenna conne
ctor
.
2
)
MAIN/-1 UNIT
UNSOLDER
Solder
remover
Remove 1
1 screws from t
he MA
IN/-
1 UNIT
, and
3)
then remove it from th
e chassis.
MAIN/-1 UNIT
Chassis
Screws×11
47
49
