Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
5-13a
March 2019
C669 4030022630 S.CER 0402N100C500CT B 37.1/54.5
C670 4030022520 S.CER 0402N1R0B500CT B 42.0/53.9
C671 4030022640 S.CER 0402N101J500CT B 42.1/56.8
C672 4030023010 S.CER 0402B104K160CT B 39.3/58.5
C674 4030023030 S.CER 0402B103K250CT B 26.9/68.8
C677 4030022940 S.CER 0402B104K100CT B 27.5/43.2
C678 4030023090 S.CER 0402B102K500CT B 31.5/41.9
C679 4030023090 S.CER 0402B102K500CT B 37.1/56.1
C680 4030023090 S.CER 0402B102K500CT B 36.2/56.2
C681 4030022940 S.CER 0402B104K100CT B 35.3/56.2
C682 4030023000 S.CER 0402B683K100CT B 22.8/65.8
C683 4030022940 S.CER 0402B104K100CT B 24.1/68.2
C684 4030023010 S.CER 0402B104K160CT B 36.2/54.5
C687 4030023010 S.CER 0402B104K160CT B 25.2/36.6
C688 4030019560 S.CER GRM21BB31C106KE15L B 23.8/36.4
C689 4030023090 S.CER 0402B102K500CT B 29.0/27.2
C693 4030022940 S.CER 0402B104K100CT T 16.4/15.5
C694 4030023090 S.CER 0402B102K500CT [#13] B 18.8/82.1
4030023090 S.CER 0402B102K500CT [#14]
4030023090 S.CER 0402B102K500CT [#16]
4030023090 S.CER 0402B102K500CT [#17]
C695 4030023010 S.CER 0402B104K160CT T 18.8/7.4
C696 4030023010 S.CER 0402B104K160CT T 15.9/11.4
C698 4030023010 S.CER 0402B104K160CT B 39.9/47.0
C699 4030023010 S.CER 0402B104K160CT B 43.2/42.2
C700 4030023090 S.CER 0402B102K500CT B 44.2/42.2
C701 4030023090 S.CER 0402B102K500CT B 25.7/33.6
C703 4030023000 S.CER 0402B683K100CT [#13] T 21.7/11.2
4030023000 S.CER 0402B683K100CT [#14]
4030023000 S.CER 0402B683K100CT [#16]
4030023000 S.CER 0402B683K100CT [#17]
C704 4030023090 S.CER 0402B102K500CT [#13] T 22.8/17.0
4030023090 S.CER 0402B102K500CT [#14]
4030023090 S.CER 0402B102K500CT [#16]
4030023090 S.CER 0402B102K500CT [#17]
C705 4030023090 S.CER 0402B102K500CT [#13] T 24.9/13.7
4030023090 S.CER 0402B102K500CT [#14]
4030023090 S.CER 0402B102K500CT [#16]
4030023090 S.CER 0402B102K500CT [#17]
C708 4030023090 S.CER 0402B102K500CT T 26.6/20.9
C709 4030021240 S.CER C1005 JB 1C 105K-T [#13] B 36.3/4.4
4030021240 S.CER C1005 JB 1C 105K-T [#14]
4030021240 S.CER C1005 JB 1C 105K-T [#16]
4030021240 S.CER C1005 JB 1C 105K-T [#17]
C711 4030023090 S.CER 0402B102K500CT B 39.1/33.8
C712 4030022920 S.CER 0402N820J500CT B 31.2/45.6
C713 4030022920 S.CER 0402N820J500CT B 24.5/42.4
C714 4030020000 S.CER C1005 JB 1A 105K-T B 31.3/65.3
C715 4030023820 S.CER 0603B104K250CT B 26.7/63.6
C716 4030023210 S.CER 0402B472K500CT B 34.1/64.8
C717 4030023210 S.CER 0402B472K500CT B 26.9/58.1
C718 4030023210 S.CER 0402B472K500CT B 31.5/27.6
C719 4030023210 S.CER 0402B472K500CT B 40.0/18.9
C720 4550008210 S.TAN 267M3502 104MR [#13] B 5.8/15.6
4550008210 S.TAN 267M3502 104MR [#14]
4550008210 S.TAN 267M3502 104MR [#16]
4550008210 S.TAN 267M3502 104MR [#17]
C721 4550008210 S.TAN 267M3502 104MR [#13] B 9.1/20.4
4550008210 S.TAN 267M3502 104MR [#14]
4550008210 S.TAN 267M3502 104MR [#16]
4550008210 S.TAN 267M3502 104MR [#17]
C722 4030021240 S.CER C1005 JB 1C 105K-T [#13] B 34.5/15.4
4030021240 S.CER C1005 JB 1C 105K-T [#14]
4030021240 S.CER C1005 JB 1C 105K-T [#16]
4030021240 S.CER C1005 JB 1C 105K-T [#17]
C723 4030021240 S.CER C1005 JB 1C 105K-T B 26.5/72.0
C724 4030023090 S.CER 0402B102K500CT B 35.9/58.6
C725 4030023090 S.CER 0402B102K500CT T 37.7/21.4
C727 4030023090 S.CER 0402B102K500CT B 43.9/57.2
C730 4030023090 S.CER 0402B102K500CT B 21.5/55.5
J1 6510030220 S.CON 50RF-JMCS-G-1B-TF
(N) (LF) (SN) B 35.5/23.0
J2 6510031390 S.CON 15FXVL-RSM1-GAN-TF-1 (HF) T 9.4/7.9
J3 6510023480 S.CON AYU1-1P-02676-120-TF [#13] B 23.2/96.1
6510023480 S.CON AYU1-1P-02676-120-TF [#14]
6510023480 S.CON AYU1-1P-02676-120-TF [#16]
6510023480 S.CON AYU1-1P-02676-120-TF [#17]
J4 6510031380 S.CON 31FXVL-RSM1-GAN-TF-1 (HF) T 24.4/24.8
DS2 5040003550 S.LED NSSW208T T 13.8/35.5
DS3 5040003550 S.LED NSSW208T T 24.8/35.5
DS4 5040003550 S.LED NSSW208T T 35.8/35.5
DS5 5030004360 LCD TM128160D1CIWUGND
S23 2260003320 S.SWI SKRTLAE010 B 2.1/83.2
S24 2260003320 S.SWI SKRTLAE010 B 2.1/44.4
S25 2260003320 S.SWI SKRTLAE010 B 2.1/34.4
EP3 6910023920 S.BEA BLM15GA750SN1D [#13] B 38.5/16.4
6910023920 S.BEA BLM15GA750SN1D [#14]
6910023920 S.BEA BLM15GA750SN1D [#16]
6910023920 S.BEA BLM15GA750SN1D [#17]
EP4 6910023920 S.BEA BLM15GA750SN1D [#13] B 36.9/15.3
6910023920 S.BEA BLM15GA750SN1D [#14]
6910023920 S.BEA BLM15GA750SN1D [#16]
6910023920 S.BEA BLM15GA750SN1D [#17]
EP9 6910020610 S.BEA BLM15BD102SN1D [#13] B 18.4/90.9
6910020610 S.BEA BLM15BD102SN1D [#14]
6910020610 S.BEA BLM15BD102SN1D [#16]
6910020610 S.BEA BLM15BD102SN1D [#17]
EP10 6910020610 S.BEA BLM15BD102SN1D T 34.7/22.6
EP11 6910020610 S.BEA BLM15BD102SN1D T 30.8/20.7
EP12 6910020610 S.BEA BLM15BD102SN1D T 25.0/21.2
EP13 6910020610 S.BEA BLM15BD102SN1D T 17.7/28.7
EP14 6910020610 S.BEA BLM15BD102SN1D T 23.2/21.2
EP16 6910020610 S.BEA BLM15BD102SN1D T 17.7/27.8
EP19 6910020610 S.BEA BLM15BD102SN1D T 22.3/21.2
The underlined parts have been updated from the previous version of the addendum, or the original page.
[LOGIC-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
[LOGIC-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
