Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
5-19a
March 2019
C616 4030023090 S.CER 0402B102K500CT T 24.8/92.4
C622 4030023060 S.CER 0402B183K250CT T 46.7/42.3
C623 4030023060 S.CER 0402B183K250CT T 46.7/40.7
C624 4030023010 S.CER 0402B104K160CT T 46.6/38.4
C627 4030023010 S.CER 0402B104K160CT B 10.8/9.2
C628 4030023010 S.CER 0402B104K160CT B 13.9/5.3
C629 4050000340 S.FEE NFM21PC224R1C3D B 32.9/6.7
C631 4030022590 S.CER 0402N8R0C500CT [#13] B 10.2/18.3
4030022590 S.CER 0402N8R0C500CT [#14]
4030022560 S.CER 0402N5R0B500CT [#16]
4030022560 S.CER 0402N5R0B500CT [#17]
4030022590 S.CER 0402N8R0C500CT [#23]
4030022590 S.CER 0402N8R0C500CT [#24]
4030022560 S.CER 0402N5R0B500CT [#27]
4030022590 S.CER 0402N8R0C500CT [#33]
4030022590 S.CER 0402N8R0C500CT [#34]
4030022560 S.CER 0402N5R0B500CT [#36]
C632 4030022720 S.CER 0402N1R5B500CT [#13] B 7.6/17.6
4030022720 S.CER 0402N1R5B500CT [#14]
4030022810 S.CER 0402N330J500CT [#16]
4030022810 S.CER 0402N330J500CT [#17]
4030022720 S.CER 0402N1R5B500CT [#23]
4030022720 S.CER 0402N1R5B500CT [#24]
4030022810 S.CER 0402N330J500CT [#27]
4030022720 S.CER 0402N1R5B500CT [#33]
4030022720 S.CER 0402N1R5B500CT [#34]
4030022810 S.CER 0402N330J500CT [#36]
C633 4030023010 S.CER 0402B104K160CT B 11.1/18.7
C634 4030023010 S.CER 0402B104K160CT B 13.0/24.2
C635 4030023010 S.CER 0402B104K160CT B 12.1/28.8
C636 4030023010 S.CER 0402B104K160CT B 13.1/15.0
C637 4030023010 S.CER 0402B104K160CT B 12.2/13.7
C638 4030023010 S.CER 0402B104K160CT B 25.5/57.0
C639 4030023090 S.CER 0402B102K500CT B 40.6/108.4
C640 4030023090 S.CER 0402B102K500CT B 45.6/104.3
C641 4030023010 S.CER 0402B104K160CT T 43.6/46.2
C642 4030023010 S.CER 0402B104K160CT T 47.9/39.2
C643 4030023010 S.CER 0402B104K160CT T 41.7/43.5
C644 4030023200 S.CER 0402B471K500CT T 48.0/41.1
C645 4030023010 S.CER 0402B104K160CT T 42.1/50.2
C646 4030019560 S.CER GRM21BB31C106KE15L T 32.8/91.3
C647 4030023010 S.CER 0402B104K160CT T 28.1/89.8
C648 4030023090 S.CER 0402B102K500CT B 12.2/60.3
C649 4030023090 S.CER 0402B102K500CT B 10.2/61.7
C650 4030023010 S.CER 0402B104K160CT T 19.8/15.8
C651 4030023010 S.CER 0402B104K160CT T 13.8/21.2
C652 4030023010 S.CER 0402B104K160CT T 11.7/15.2
C653 4030021240 S.CER C1005 JB 1C 105K-T T 22.0/97.1
C656 4030023090 S.CER 0402B102K500CT T 15.6/7.8
C660 4030023090 S.CER 0402B102K500CT B 6.6/67.2
C661 4030023010 S.CER 0402B104K160CT T 40.6/46.4
C662 4030023010 S.CER 0402B104K160CT T 41.2/44.9
C663 4030023010 S.CER 0402B104K160CT T 33.2/85.4
C664 4030023010 S.CER 0402B104K160CT B 36.5/41.7
C665 4030023070 S.CER 0402B223K250CT B 20.7/75.2
C666 4030023010 S.CER 0402B104K160CT T 34.3/22.5
C667 4030023090 S.CER 0402B102K500CT B 14.0/15.0
C668 4030023090 S.CER 0402B102K500CT B 12.0/18.7
C669 4030023090 S.CER 0402B102K500CT B 13.9/24.2
C670 4030023090 S.CER 0402B102K500CT B 13.0/29.4
C671 4030022640 S.CER 0402N101J500CT B 6.0/21.5
C672 4030022640 S.CER 0402N101J500CT B 6.9/16.1
C673 4030023090 S.CER 0402B102K500CT T 42.4/45.6
C674 4030023090 S.CER 0402B102K500CT T 16.1/22.4
C675 4030023090 S.CER 0402B102K500CT T 6.5/15.7
C676 4030023090 S.CER 0402B102K500CT T 19.3/79.5
C677 4030019560 S.CER GRM21BB31C106KE15L [#13] B 24.5/68.6
4030019560 S.CER GRM21BB31C106KE15L [#14]
4030019560 S.CER GRM21BB31C106KE15L [#16]
4030019560 S.CER GRM21BB31C106KE15L [#17]
C680 4030023010 S.CER 0402B104K160CT [#13] T 32.7/86.6
4030023010 S.CER 0402B104K160CT [#14]
4030023010 S.CER 0402B104K160CT [#16]
4030023010 S.CER 0402B104K160CT [#17]
C681 4030023010 S.CER 0402B104K160CT [#13] T 35.2/81.9
4030023010 S.CER 0402B104K160CT [#14]
4030023010 S.CER 0402B104K160CT [#16]
4030023010 S.CER 0402B104K160CT [#17]
C682 4030023010 S.CER 0402B104K160CT T 30.1/71.4
C683 4030023090 S.CER 0402B102K500CT B 43.1/94.4
C684 4030023090 S.CER 0402B102K500CT B 38.9/95.7
C694 4030023090 S.CER 0402B102K500CT T 36.7/58.4
C704 4030023090 S.CER 0402B102K500CT T 40.1/58.6
C706 4030023090 S.CER 0402B102K500CT T 38.3/58.6
C712 4030023820 S.CER 0603B104K250CT T 7.1/19.1
C713 4550008850 S.TAN F931C227MNC T 25.8/29.5
C715 4030023010 S.CER 0402B104K160CT T 47.2/43.6
J1 6450000870 CON HEC2711-01-020
J2 6450000131 CON HSJ1102-018540
J4 6510021901 S.CON BM02B-ASRS-TF (LF) (SN) T 13.0/4.0
J5 6450001060 CON HSJ1493-01-010
J6 6510031230 S.CON 50P4.5-JMCS-G-TF (N) (1) T 35.7/54.3
MC1 7700003060 MIC F6027AP-SBC-462
S1 2260003640 SWI SKHLLCA010
EP3 6910014640 S.BEA MPZ2012S221A-T T 39.3/14.4
EP4 6910014640 S.BEA MPZ2012S221A-T T 19.5/121.0
EP5 6910014730 S.BEA MPZ2012S331A-T T 37.0/102.8
EP6 6910014730 S.BEA MPZ2012S331A-T B 40.2/110.9
EP7 6910014730 S.BEA MPZ2012S331A-T B 41.8/106.3
EP10 6910014730 S.BEA MPZ2012S331A-T T 13.9/8.6
EP11 6910014730 S.BEA MPZ2012S331A-T B 39.7/103.7
EP13 6910020610 S.BEA BLM15BD102SN1D T 15.7/47.5
EP14 6910020610 S.BEA BLM15BD102SN1D T 12.5/47.6
EP15 6910014640 S.BEA MPZ2012S221A-T T 39.7/18.7
EP16 6910014640 S.BEA MPZ2012S221A-T T 18.5/89.0
EP18 6910020610 S.BEA BLM15BD102SN1D T 27.7/56.8
EP19 6910020610 S.BEA BLM15BD102SN1D T 23.5/54.5
EP20 6910020610 S.BEA BLM15BD102SN1D T 26.6/42.9
EP21 6910020610 S.BEA BLM15BD102SN1D T 32.6/34.2
EP23 6910014730 S.BEA MPZ2012S331A-T T 12.2/8.6
EP24 6910014730 S.BEA MPZ2012S331A-T B 42.4/92.3
EP25 6910020610 S.BEA BLM15BD102SN1D B 36.5/87.2
EP26 6910020610 S.BEA BLM15BD102SN1D B 40.1/95.7
EP28 6910020610 S.BEA BLM15BD102SN1D T 26.9/110.8
EP29 6910014640 S.BEA MPZ2012S221A-T T 30.3/110.0
EP30 6910014640 S.BEA MPZ2012S221A-T B 34.9/10.9
EP31 6910020610 S.BEA BLM15BD102SN1D T 19.5/111.2
The underlined parts have been updated from the previous version of the addendum, or the original page.
[MAIN-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
[MAIN-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
